| Place of Origin: | Made in China |
| Brand Name: | Infinity Machine |
| Certification: | CE, ISO |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Keyboard Durability Testing Machine: Standard export wooden case with operation manual and video inside. |
| Delivery Time: | Durability Keyboard Test Machine: Shipped in 15 days after payment |
| Payment Terms: | Keypad Key Durability Tester Machine: L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 sets per month |
| Clamp Area(W*D): | 400*300mm | Table Adjust: | 0~100mm |
|---|---|---|---|
| Test Load: | Base Load 80gf,10gf,20gf,30gf,50gf Can Be Added | Test Speed: | 36~240 Times / Min Or 120~360 Times / Min |
| Weight: | 100kg / 90kg | Dimension(W*D*H): | 530*460*980mm / 600*400*720mm |
| Power: | AC220V 50Hz 5A Or Specified By User | Warranty: | 1 Year |
| High Light: | utm universal testing machine,universal test equipment |
||
Purpose:
Keyboard durable tester is used for life time test of computer keyboard, note-book keyboard, other knobs and switches, can test many parts together at the same time (Every parts can be tested at many different places) Can test Max.120 keys for keyboard.
Feature:
Use the AC speeed adjustable motor driving, with low noise and durability.
To use the weight to click the keys, the clicking force is adjustable from 100~200gf, the clicking force is precise.
Because of using the special transmission design, the max clicking speed can be 360 cycles / Min, which can raise the testing efficiency.
Use the sliding block design, can move the fixture forth and back, left and right, can test any key.
Specification:
| Clamp area (WxD) | 400x300mm | |
| Up and down range of testing table | 0~100mm (Hand moving) | |
| Test load | base load 80gf, 10gf, 20gf, 30gf, 50gf can be added accordingly | |
| Test speed | 36~240 times/min or 120~360 times/min | |
| Test cycle | 0~99,999,999times (Adjustable) | |
| Dimension (WxDxH) | 530x460x980mm | 600x400x720mm |
| Weight | About 120 kg | About 90 kg |
| Power Supply | AC220V 50Hz 5A or specified by user | |
