| Place of Origin: | MADE IN CHINA |
| Brand Name: | INFINITY |
| Certification: | CE ISO |
| Model Number: | IE31A1 Series |
| Model number: | IE31A1 Series |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Clear sheet+sponge+wood carton |
| Delivery Time: | 20-30 days after order confirmed |
| Payment Terms: | TT PAYPAL Moneygram and so on |
| Supply Ability: | 200 sets / month |
| Specimen Holder: | Stainless Steel Sample Frame 2 Layers, Adjustable Height, Bearing Weight Of 30kg / Layer. | Temperature Uniformity: | ≦2.0℃ |
|---|---|---|---|
| Temperature Range: | -65℃ ～ +150℃ | Equipment Overview: | For Users To The Whole Machine (or Parts), Electrical Appliances, Instruments, Materials, Coating, Coating For The Corresponding Climate Mutation Test, Suitable For Electrical, Electronics, Machinery Industry And Other Products, Parts, Materials, Such As H |
| Temperature Fluctuation: | ±1℃ | Temperature Recovery Time: | Within 5 Mint |
| Box Door: | Open The Door Alone, Add The Door Frame Heating Wire At The Door Frame To Prevent Condensation At The Door Frame At Low Temperature. |
High Reliability Hot and Cold Impact Test Chamber 500x400x400mm for Experimental Data
One of the key features of the Thermal Shock Test Chamber is its heating rate. It can heat up from RT to +150℃ in about 50 minutes, making it a fast and efficient way to perform thermal shock testing. The heating rate is achieved through a heat storage area in the chamber.
The cooling medium used in the Thermal Shock Test Chamber is non-fluorine environmental protection refrigerant R404A R23. This refrigerant complies with environmental protection regulations and is safe and non-toxic.
The Thermal Shock Test Chamber is equipped with various safety protection devices to ensure safe operation. The heater has air defense incineration protection and over current protection. The circulation fan has over current overload protection, while the compressor has high pressure protection, overheat protection, over current protection, and over voltage under reverse phase protection. The chamber also has a circuit breaker and leakage protection.
The temperature uniformity of the Thermal Shock Test Chamber is ≦2.0℃, which ensures that the specimen is exposed to consistent temperatures during testing. The chamber also has an observation window installed on the box door. The W300 *H400mm observation window is made of multi-layer insulating electric thermal coated glass, which effectively provides heat preservation and prevents condensation.
Overall, the Thermal Shock Test Chamber is a reliable and efficient equipment used in various industries such as electronics, aerospace, and automotive to test the durability and reliability of materials under extreme temperature changes.
This product is also known as Hot and Cold Impact Test Chamber.
| Product Name | Thermal Shock Test Chamber |
| Model Number | IE31A1 Series |
| Heating Rate | Up From RT To +150℃ About 50min Is Required(or Specify) |
| Cooling Rate | Down From RT To -55℃ About 75min Is Required(or Specify) |
| Temperature Uniformity | ≦2.0℃ |
| Temperature Recovery Time | Within 5 Mint |
| Condenser Mode | Water-cooled |
| Standards | GB/T2423.1-2001 Low Temperature Test Method; GB/T2423.2-2001; GB/T2423.22-1989 Temperature Change Test; Standard GJB150.3-86; Standard GJB150.4-86; Standard GJB150.5-86; GJB150.5-86 Temperature Impact Test GJB360.7-87 Temperature Shock Test; GJB367. 2-87 405 Temperature Shock Test; J / T10187-91Y73 Series Temperature Change Test Box-three-box Type; Meet The Standard IEC68-2-14_ Test Method _ Temperature Change. |
| Thermal Insulation Box |
|
| Features |
|
| Source | AC380V;50Hz;18KW(or Specify) |
The INFINITY IE31A1 Series Thermal Shock Test Chamber is suitable for a wide range of product application occasions and scenarios. It can be used in the electronics industry to test the reliability and durability of electronic components and devices when exposed to extreme temperature changes. It can also be used in the automotive industry to test the performance of car parts and components when subjected to temperature fluctuations. Furthermore, it can be used in the aerospace industry to test the resistance of aircraft parts and equipment to temperature changes during flight.
The product comes with a temperature recovery time of within 5 minutes, making it highly efficient and reliable. The cooling medium used in the product is a non-fluorine environmental protection refrigerant R404A R23, which complies with environmental protection regulations and is safe and non-toxic. The product's carton size is WxHxD(mm): 1480×1450 ×1950 (or specify) and is packaged with clear sheets, sponge, and a wood carton for safe delivery.
The INFINITY IE31A1 Series Thermal Shock Test Chamber also comes with a water-cooled condenser mode, which ensures that the product functions optimally without overheating. Additionally, the product is equipped with several safety protection devices such as heater air defense incineration protection, heater over current protection, circulation fan over current overload protection, compressor high-pressure protection, compressor overheat protection, compressor over current protection, overvoltage under reverse phase protection, circuit breaker and leakage protection.
The minimum order quantity for this product is 1, and the price is negotiable. The delivery time for the product is 20-30 days after order confirmation. Payment methods accepted include TT, PayPal, Moneygram, and others. The product has a supply ability of 200 sets per month, making it readily available for purchase.
Introducing the INFINITY Thermal Shock Test Chamber, Model Number IE31A1 Series - the perfect solution for your testing needs. Our product is proudly MADE IN CHINA and is certified with CE and ISO. The minimum order quantity is 1 and the price is negotiable. The packaging details include a clear sheet, sponge, and wood carton. The delivery time for the product is 20-30 days after order confirmation and payment terms include TT, PAYPAL, Moneygram and so on. Our supply ability is 200 sets/month.
The IE31A1 Series Thermal Shock Test Chamber features a Stainless Steel Sample Frame 2 Layers with Adjustable Height and a Bearing Weight Of 30kg / Layer. The box door can be opened alone and includes a door frame heating wire to prevent condensation at the door frame at low temperature. The cooling rate (cold storage area) is down from RT to-55℃ in about 75min (or specify). Our product meets the following standards: GB/T2423.1-2001 Low Temperature Test Method; GB/T2423.2-2001; GB/T2423.22-1989 Temperature Change Test; Standard GJB150.3-86; Standard GJB150.4-86; Standard GJB150.5-86; GJB150.5-86 Temperature Impact Test GJB360.7-87 Temperature Shock Test; GJB367. 2-87 405 Temperature Shock Test; J / T10187-91Y73 Series Temperature Change Test Box-three-box Type; Meet The Standard IEC68-2-14_ Test Method _ Temperature Change.
Order your Thermal Shock Test Chamber today and experience the quality and reliability of the INFINITY brand.
The Thermal Shock Test Chamber is designed with high-quality materials and advanced technology to provide reliable and accurate testing results. Our product technical support and services include:
- Installation guidance and technical support
- Training on proper usage and maintenance
- Troubleshooting and repair services
- Calibration and verification services
- Replacement parts and accessories
Our team of experts is dedicated to providing exceptional customer service and ensuring the optimal performance of your Thermal Shock Test Chamber. Contact us for any technical support or service inquiries.
Product Packaging:
The Thermal Shock Test Chamber is packaged in a sturdy wooden crate to ensure that it arrives at your doorstep in excellent condition. The crate is securely fastened with metal straps and includes foam padding to protect the chamber during transportation.
Shipping:
The Thermal Shock Test Chamber will be shipped via a trusted courier service that ensures timely and safe delivery to your location. Shipping charges will be added to the total cost of your order at checkout, and you will receive a tracking number once your order has been shipped.
Q: What is the brand name of the Thermal Shock Test Chamber?
A: The brand name of the Thermal Shock Test Chamber is INFINITY.
Q: What is the model number of the Thermal Shock Test Chamber?
A: The model number of the Thermal Shock Test Chamber is IE31A1 Series.
Q: Where is the Thermal Shock Test Chamber made?
A: The Thermal Shock Test Chamber is made in China.
Q: What certifications does the Thermal Shock Test Chamber have?
A: The Thermal Shock Test Chamber has CE and ISO certifications.
Q: What is the minimum order quantity for the Thermal Shock Test Chamber?
A: The minimum order quantity for the Thermal Shock Test Chamber is 1.
Q: What is the price of the Thermal Shock Test Chamber?
A: The price of the Thermal Shock Test Chamber is negotiable.
Q: What are the packaging details for the Thermal Shock Test Chamber?
A: The packaging details for the Thermal Shock Test Chamber are clear sheet+sponge+wood carton.
Q: What is the delivery time for the Thermal Shock Test Chamber?
A: The delivery time for the Thermal Shock Test Chamber is 20-30 days after order confirmed.
Q: What are the payment terms for the Thermal Shock Test Chamber?
A: The payment terms for the Thermal Shock Test Chamber are TT, PayPal, Moneygram, and so on.
Q: What is the supply ability of the Thermal Shock Test Chamber?
A: The supply ability of the Thermal Shock Test Chamber is 200 sets per month.
