| Place of Origin: | MADE IN CHINA |
| Brand Name: | INFINITY |
| Certification: | CE ISO |
| Model Number: | IE31 Series |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Clear sheet+sponge+wood carton |
| Delivery Time: | 20-30 days after order confirmed |
| Payment Terms: | TT PAYPAL Moneygram and so on |
| Supply Ability: | 200 sets / month |
| Thermal Insulation Chamber: | ● Outer Wall Material: High Quality Carbon Steel Plate, The Surface For Electrostatic Color Spray Plastic Treatment. The Left Side Diameter Of The Box Is φ 50mm Hole ● Inner Wall Material: SUS304 # Fog Surface Stainless Steel Plate. ● Thermal Insulation Ma | Standards:: | GB/T2423.1-2001 Low Temperature Test Method; GB/T2423.2-2001; GB/T2423.22-1989 Temperature Change Test; Military Standard GJB150.3-86; Military Standard GJB150.4-86; Military Standard GJB150.5-86; GJB150.5-86 Temperature Impact Test; GJB360.7-87 Temperatur |
|---|---|---|---|
| Product Name: | Programmed Cold And Hot Impact Test Chamber | Temperature Range: | -40℃ ～ +150℃ |
| Carton Size: WxHxD(mm): | 1480×1450 ×1950(or Specify) | Condenser Mode: | Air-cooled(or Specify) |
| Features:: | Energy Saving And Consumption Reduction: Use Gas-liquid Bypass Mode To Adjust The Cooling Capacity To Achieve Constant Temperature And Humidity. Simple Operation: Programmed Color LCD Touch Controller Reference Group PID Control; Experimental Data Recordin | Observation Window: | W300 *H400mm Observation Window Is Installed On The Box Door. Multi-layer Insulating Electric Thermal Coated Glass Can Effectively Provide Heat Preservation And Prevent Condensation. |
1480×1450×1950 Programmable Hot Cold Shock Test Chamber with Air-cooled Condenser Mode
The Thermal Shock Test Chamber features energy-saving and consumption reduction capabilities. It uses a gas-liquid bypass mode to adjust the cooling capacity and achieve constant temperature and humidity. The operation is simple with a programmed color LCD touch controller and reference group PID control. The experimental data recording and processing mode is flexible.
The key parts of the Programmable Hot Cold Shock Test Chamber are imported to ensure the service life and reliability. The cooling rate (cold storage area) is down from RT to -40℃, requiring about 55 minutes (or as specified). The heating rate (heat storage area) is up from RT to +150℃, requiring about 35 minutes (or as specified).
| Product Name: | Programmed Cold And Hot Impact Test Chamber |
| Standards: | GB/T2423.1-2001 Low Temperature Test Method; GB/T2423.2-2001; GB/T2423.22-1989 Temperature Change Test; Military Standard GJB150.3-86; Military Standard GJB150.4-86; Military Standard GJB150.5-86; GJB150.5-86 Temperature Impact Test; GJB360.7-87 Temperature Shock Test; GJB367.2-87 405 Temperature Shock Test; J/T10187-91Y73 Series Temperature Change Test Box-three Box Type; Meet The Standard IEC68-2-14_ Test Method N_ Temperature Change. |
| Specimen Holder: | Stainless Steel Sample Frame 2 Layers, Adjustable Height, Bearing Weight Of 30kg / Layer. |
| Internal Box Size: | WxHxD(mm): 500x400x400(or Specify) |
| Temperature Range: | -40℃ ～ +150℃ |
| Observation Window: | W300 *H400mm Observation Window Is Installed On The Box Door. Multi-layer Insulating Electric Thermal Coated Glass Can Effectively Provide Heat Preservation And Prevent Condensation. |
| Features: | Energy Saving And Consumption Reduction: Use Gas-liquid Bypass Mode To Adjust The Cooling Capacity To Achieve Constant Temperature And Humidity. Simple Operation: Programmed Color LCD Touch Controller Reference Group PID Control; Experimental Data Recording And Processing Mode Is Flexible. High Reliability: The Key Parts Are Imported Parts To Ensure The Service Life And Reliability. |
| Equipment Overview: | For Users To The Whole Machine (or Parts), Electrical Appliances, Instruments, Materials, Coating, Coating For The Corresponding Climate Mutation Test, Suitable For Electrical, Electronics, Machinery Industry And Other Products, Parts, Materials, Such As High And Low Temperature, Humidity Test, Simulate The Temperature And Humidity Changes Under The Condition Of Cold And Cold Impact Test, So As To Evaluate The Quality Of The Test Products. |
| Thermal Insulation Chamber: | ● Outer Wall Material: High Quality Carbon Steel Plate, The Surface For Electrostatic Color Spray Plastic Treatment. The Left Side Diameter Of The Box Is φ 50mm Hole ● Inner Wall Material: SUS304 # Fog Surface Stainless Steel Plate. ● Thermal Insulation Material: Hard Polyurethane Foam Thermal Insulation Layer + Glass Fiber. |
| Chamber Door: | Open The Door Alone, Add The Door Frame Heating Wire At The Door Frame To Prevent Condensation At The Door Frame At Low Temperature. |
The IE31 Series Programmable Hot Cold Shock Test Chamber is designed to meet the standards of GB/T2423.1-2001, GB/T2423.2-2001, GB/T2423.22-1989, Military Standard GJB150.3-86, Military Standard GJB150.4-86, Military Standard GJB150.5-86, GJB150.5-86, GJB360.7-87, GJB367.2-87 405, J/T10187-91Y73 Series, and IEC68-2-14_ Test Method N_ Temperature Change. This means that it is suitable for testing a wide range of products in different industries.
The IE31 Series Programmable Hot Cold Shock Test Chamber has a source of AC380V, 50Hz, and 18KW (or specify). It has a temperature uniformity of ≦2.0℃, ensuring accurate and consistent test results. The energy-saving and consumption reduction feature of this Thermal Shock Test Chamber is achieved by its gas-liquid bypass mode, which adjusts the cooling capacity to achieve constant temperature and humidity.
The Programmable Hot Cold Shock Test Chamber is easy to operate, thanks to its programmed color LCD touch controller reference group PID control. The experimental data recording and processing mode is flexible, making it easy to manage and analyze test results. The key parts of this Thermal Shock Test Chamber are imported, ensuring high reliability and a long service life.
The IE31 Series Programmable Hot Cold Shock Test Chamber has a carton size of WxHxD(mm) of 1480×1450×1950 (or specify). It is packaged with clear sheet+sponge+wood carton, ensuring its safety during transportation. The delivery time for this Thermal Shock Test Chamber is 20-30 days after order confirmation, and the payment terms are TT, PayPal, MoneyGram, and so on. The minimum order quantity is one, and the price is negotiable. This Programmable Hot Cold Shock Test Chamber has a supply ability of 200 sets/month, ensuring its availability for different applications.
Experience the high-quality Programmable Hot Cold Shock Test Chamber by INFINITY, Model Number IE31 Series, which is manufactured in China. This product is certified with CE and ISO, ensuring product quality and safety. The minimum order quantity is 1, and the price is negotiable. The packaging details include a clear sheet, sponge, and wooden carton, ensuring the safety of the product during transportation. Delivery time is 20-30 days after order confirmation, and we accept various payment methods such as TT, PayPal, Moneygram, and more. Our supply ability is 200 sets per month, ensuring timely delivery to our customers.
The specimen holder of this product is specifically designed with a Stainless Steel Sample Frame, 2 Layers, Adjustable Height, Bearing Weight Of 30kg / Layer, ensuring stability and durability during testing. The safety protection device includes Heater Air Defense Incineration Protection, Heater Over Current Protection, Circulation Fan Over Current Overload Protection, Compressor High Pressure Protection, Compressor Overheating Protection, Compressor Over Current Protection, Over Voltage Under Reverse Phase Protection, Circuit Breaker, and Leakage Protection, ensuring the safety of the user and the product.
The internal box size of the Programmable Hot Cold Shock Test Chamber is WxHxD(mm): 500x400x400 (or Specify), and the carton size is WxHxD(mm): 1480×1450 ×1950 (or Specify). The cooling medium used is Non-fluorine Environmental Protection Refrigerant R404A R23 Comply With Environmental Protection Regulations, Safe And Non-toxic, ensuring the safety of the environment and the user.
The Thermal Shock Test Chamber is designed to test the ability of a product to withstand sudden changes in temperature. Our product technical support and services for this chamber include:
Our team of experienced technicians and engineers are dedicated to ensuring that your Thermal Shock Test Chamber operates effectively and efficiently. Contact us for more information on our product technical support and services.
Product Packaging:
The Thermal Shock Test Chamber will be packaged in a sturdy wooden crate to ensure maximum protection during shipping. The crate will be sealed with high-quality strapping to prevent any movement or damage during transportation.
Shipping:
The Thermal Shock Test Chamber will be shipped via a reliable and trusted freight carrier. The carrier will be chosen based on the destination and delivery timeframe required by the customer. Once shipped, the customer will be provided with a tracking number to monitor the shipment's progress.
What is the brand name of this Thermal Shock Test Chamber?
The brand name of this Thermal Shock Test Chamber is INFINITY .
What is the model number of this Thermal Shock Test Chamber?
The model number of this Thermal Shock Test Chamber is IE31 Series .
Where is this Thermal Shock Test Chamber made?
This Thermal Shock Test Chamber is MADE IN CHINA .
What certifications does this Thermal Shock Test Chamber have?
This Thermal Shock Test Chamber has CE ISO certifications.
What is the minimum order quantity for this Thermal Shock Test Chamber?
The minimum order quantity for this Thermal Shock Test Chamber is 1 .
What is the price of this Thermal Shock Test Chamber?
The price of this Thermal Shock Test Chamber is negotiate .
What are the packaging details for this Thermal Shock Test Chamber?
The packaging details for this Thermal Shock Test Chamber are clear sheet+sponge+wood carton .
What is the delivery time for this Thermal Shock Test Chamber?
The delivery time for this Thermal Shock Test Chamber is 20-30 days after order confirmed.
What are the payment terms for this Thermal Shock Test Chamber?
The payment terms for this Thermal Shock Test Chamber are TT PAYPAL Moneygram and so on .
What is the supply ability of this Thermal Shock Test Chamber?
The supply ability of this Thermal Shock Test Chamber is 200 sets / month .
