Place of Origin: | Made in China |
Brand Name: | Infinity Machine |
Certification: | CE, ISO |
Model Number: | RS-8224 |
Minimum Order Quantity: | 1 |
---|---|
Price: | Negotiable |
Packaging Details: | Standard export wooden case with operation manual and video inside. |
Delivery Time: | Shipped in 15 days after payment |
Payment Terms: | D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 200 sets per month |
Control Instruments: | The Korea TEMI300 Large LCD Programmable Controller | Temp-range: | 0~100℃ |
---|---|---|---|
Humid-range: | 35~98%RH | Exterior Material: | Stainless Steel SUS304 (matt) |
Interior Material: | Stainless Steel SUS304 (mirror) | Cooling Time: | +20℃~0℃ About 40min |
Heating Time: | +20℃~100℃ About 30min | Interior Dim: | W500 X D400 X H500mm |
Weight: | About 100kg | Power: | AC220V 50Hz 10A Or Specified By User |
Capacity: | 250L | Humidity: | 85%~98%RH |
Temperature Range: | ± 0.5℃ | Salt Spray Subside: | 1.0~2.0ml/80cm2/h |
Test Room Size: | 900x600x450mm | Machine Size: | 1460x910x1280mm |
Lab Temperature: | NSS.ACSS 35°C ± 1 °C / CASS 50°C ± 1 °C | Saturator Temperature: | NSS.ACSS 35°C ± 1 °C / CASS 50°C ± 1 °C |
Saturator Temperature: | NSS.ACSS 35°C ± 1 °C / CASS 50°C ± 1 °C | Power Supply: | AC220V 15A Or Specified By User |
Water Way: | Atered By Itself While Lack Of Water | Spray Work Time: | Precise Spray Can Work 2000 Hours Without Crystalled Jam. |
Spray Work Time: | Precise Spray Can Work 2000 Hours Without Crystalled Jam. | Spray Work Time: | Precise Spray Can Work 2000 Hours Without Crystalled Jam. |
Body Material: | Japanese PVC Environmental Protection & High Anti-aging Capability | Body Material: | Japanese PVC Environmental Protection & High Anti-aging Capability |
Spray Material: | Transparent PVC | Spray Material: | Transparent PVC |
SSR: | Precisely Digital Thermal Controller With Spray Protection System. | SSR: | Precisely Digital Thermal Controller With Spray Protection System. |
Standards: | GB/T5170.8, GB/T2423.17, ISO-3768 3769 3770, ASTM-B117 B268, JIS-D0201 H8502 H8610 K5400 Z2371 | Standards: | GB/T5170.8, GB/T2423.17, ISO-3768 3769 3770, ASTM-B117 B268, JIS-D0201 H8502 H8610 K5400 Z2371 |
Application: | This Tester Is Used For The Surface Erosion Resistance Test Of Kinds Of Material Processed By Paint, Plating, Anodized. | Application: | This Tester Is Used For The Surface Erosion Resistance Test Of Kinds Of Material Processed By Paint, Plating, Anodized. |
Highlight: | environmental testing equipment,environmental testing chamber,Fire Flame Plastic Burning Test Chamber |
Fire Flame Plastic Burning Test Chamber UL 94 Standard AC 220V 50Hz
Model: RS-8224
Purpose:
This machine is designed and manufactured according to USA UL 94 standard Burning Characteristics of Plastic Material Specified for Manufacturing Equipment and Parts, GB/T2408-1996 Testing Method of Burning of Plastic Material: horizontal and vertical as well as the relevant clauses in IEC60065 for a purpose of testing the burning characteristics of plastic material.
Technical Parameters:
1. The gas used by this test apparatus is industry-level methane or coal-seam gas or liquefied petroleum gas (if possible, suggest to use the
methane with a concentration>98%). The internal diameter of burning blowtorch is Φ9.5mm+0.3mm and the length is 100mm+10mm, it
has air volume regulating hole.
2. The fire flame is convenient to be adjusted, according to the standard; it can be adjusted from 20mm+1mm to 125mm+10mm.
3. The burning time and residual burning time can be adjusted from a range from 0-99 minutes and 99 seconds.
Features:
This tester provides one flame burning source through which the burning time, residual flame time and residual burning time can manually adjusted.
Accessories:
Technical Support and Services:
We are committed to providing our customers with exceptional technical support and services.
We offer a comprehensive range of services to ensure that your product is subjected to rigorous testing and quality control.
Our team of specialists is dedicated to providing the highest quality technical support and services for ourr test machines. If you have any questions or need assistance, please feel free contact us.
Our workshop:
Technical Support and Services:
We are committed to providing our customers with exceptional technical support and services.
We offer a comprehensive range of services to ensure that your product is subjected to rigorous testing and quality control.
Our team of specialists is dedicated to providing the highest quality technical support and services for ourr test machines. If you have any questions or need assistance, please feel free contact us.
We focus on providing excellent technical support and service to our customers to ensure that your products undergo rigorous testing and quality control. We offer a full range of services, from initial technical advice and assistance to installation, setup, training and repair services after delivery. We also offer a variety of customized services to meet your specific needs and ensure that your equipment can achieve the best performance. In addition, we provide spare parts and consumables supply services to ensure the continuous operation of your equipment. Our team of experts is dedicated to providing the highest quality technical support and service for our test machines to meet your various needs. If you have any questions or need help, please feel free to contact us and we will be happy to help you.
Packing and Shipping:
Our test machine will be packed in appropriate cardboard boxes and/or crates. The products will be shipped using standard shipping methods such as air freight, sea freight, or ground transport. Any special shipping requirements should be discussed with the supplier prior to the purchase.
The customer is responsible for all import duties, taxes and/or other fees associated with the goods. The supplier will provide all necessary documentation to facilitate customs clearance.
FAQ:
1. How to choose the most suitable Compression testing machine?
Our professional team will give you the best suggestion as long as you tell us what kind of test you need
to do and the required specification.
2. What’s the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20
working days after deposit receipt. If you are in urgent need, we can consider making special
arrangement for you.
3. Do you accept customization service?
Yes, of course, we can not only offer standard machines, but also customized machines according to
your request. Don’t hesitate to tell us your requirement, we will try our best to meet your needs.
4. Can we visit your factory before order?
Yes, warmly welcome to visit our factory.
5. Do you have customers of our country before?
Now our testing machines have been sold to more than 30 countries, like USA, Canada, Russia,UK,
Italy, Germany, European Union, India, Pakistan, Philippines, Singapore, Thailand and Vietnam,
Iran, Brazil...and so on.
6. How about your warranty?
Generally, our warranty is one year. Within the warranty period, we can offer technique support and
part parts change, necessarily, our engineers may go to your place for better service.
7. How about the packing for machine, is it safely protected during transportation?
Our machine is packed by standard export wooden carton, it won’t be damaged. We’ve delivered many
testing machines abroad by sea or by air without damage.
8. How to install and use the product?
The product is shipped with an operating instructions and video of English version.
