| Place of Origin: | Made in China |
| Brand Name: | Infinity Machine |
| Certification: | CE, ISO |
| Model Number: | OEM |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Salt Spray Corrosion Testing Chambers:Standard export wooden case with operation manual and video inside. |
| Delivery Time: | Salt Corrosion Testing Chamber: Shipped in 15 days after payment |
| Payment Terms: | D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 sets per month |
| Products: | Salt Corrosion Testing Chamber | Test Chamber: | 60L~1000L |
|---|---|---|---|
| Lab Temperature.: | NSS.ACSS 35°C±1 °C/CASS 50°C±1 °C | Saturator Temperature: | NSS.ACSS 35°C ± 1 °C / CASS 50°C ± 1 °C |
| Humidity: | 85%~98%RH | Temperature Range: | ± 0.5℃ |
| Salt Spray Subside: | 1.0~2.0ml/80cm2/h | Capacity: | 250L |
| Test Room Size: | 900x600x450mm | Machine Size: | 1460x910x1280mm |
| Lab Temperature: | NSS.ACSS 35°C ± 1 °C / CASS 50°C ± 1 °C | Power Supply: | AC220V 15A Or Specified By User |
| Water Way: | Atered By Itself While Lack Of Water | Spray Work Time: | Precise Spray Can Work 2000 Hours Without Crystalled Jam. |
| Body Material: | Japanese PVC Environmental Protection & High Anti-aging Capability | Spray Material: | Transparent PVC |
| SSR: | Precisely Digital Thermal Controller With Spray Protection System. | Standards: | GB/T5170.8, GB/T2423.17, ISO-3768 3769 3770, ASTM-B117 B268, JIS-D0201 H8502 H8610 K5400 Z2371 |
| Application: | This Tester Is Used For The Surface Erosion Resistance Test Of Kinds Of Material Processed By Paint, Plating, Anodized. | ||
| High Light: | 1000L Salt Spray Corrosion Test Chamber,GB/T2423.17 Salt Spray Corrosion Test Chamber,1000L Salt Spray Test Chamber |
||
Application:
Salt spray corrosion test chamber is widely used in various kinds of paint, electroplating, anodic oxidation surface treatment of materials corrosion resistance test. The device simulates salt spray corrosion in natural environments to assess the effects of corrosion that materials may experience during actual use. The salt spray test chamber atomizes the saline solution and exposes the surface of the sample to the salt spray environment, so as to observe and evaluate its corrosion resistance.
Salt spray test chamber is suitable for corrosion test of metal, plastic, paint, rubber, ceramic and other materials. An adjustable spray system is provided in the test chamber to adjust the concentration and spray rate of the salt spray. In addition, the test chamber has a precise temperature and humidity control system to ensure the stability and accuracy of the test process. The test of salt spray corrosion test chamber can provide valuable data and reference for material selection, product design and production process.
Standards:
Alternating Salt Spray Test Machine:
GB/T5170.8, GB/T2423.17, ISO-3768 3769 3770, ASTM-B117 B268, JIS-D0201 H8502 H8610 K5400 Z2371
Specification:
|
Test room (WxLxH) mm |
600x450x400 | 900x600x450 | 1200x850x500 | 1600x1000x600 |
|
Machine size (WxLxH) mm |
1130x630x1070 | 1460x910x1280 | 2200x1200x1450 | 2600x1450x1600 |
| Lab temperature | NSS.ACSS 35°C ± 1 °C / CASS 50°C ± 1 °C | |||
| Saturator temperature | NSS.ACSS 35°C ± 1 °C / CASS 50°C ± 1 °C | |||
| Humidity | 85%~98%RH | |||
| Temperature range | ± 0.5℃ | |||
| Salt spray subside | 1.0~2.0ml/80cm2/h | |||
| Power supply | AC220V 10A or specified by user | AC220V 15A or specified by user | AC220V 20A or specified by user | AC220V 30A or specified by user |
Features:
The alternating salt spray test chamber is a kind of test equipment with high performance and high reliability. It is manufactured with advanced technology and high-quality materials and has the following characteristics:
1. Intelligent water adding system: During the test, if there is a lack of water, the equipment can automatically water to ensure the smooth progress of the test.
2. Precision spray function: The alternating salt spray test chamber adopts precision spray technology, which can work continuously for 2000 hours without worrying about crystallization blockage, ensuring the accuracy of the test results.
3. High-quality materials: The equipment is mainly made of Japanese PVC material, which has good environmental protection performance and anti-aging ability. The spray part is made of transparent PVC material, which is easy to observe the test process.
4. Safety protection system: SSR (precise digital thermal controller with spray protection system) can ensure the safe operation of the equipment while ensuring the test effect.
Alternating salt spray test chamber is widely used in metal, plastic, paint, rubber and other materials corrosion test, to provide strong support for material selection, product design and production process.
Pictures:
Package:
Salt water testing chamber will be packaged in standard export wooden case, also, we will provide operation manual and operating video to you.
