IE4290L Flexible Environmental Salt Spray Machine for Quick Tests IE42 Series 270L 2.5KWatt

IE4290L Flexible Environmental Salt Spray Machine for Quick Tests IE42 Series 270L 2.5KWatt

IE4290L  Flexible Environmental Salt Spray Machine for Quick Tests IE42 Series 270L 2.5KWatt
IE4290L  Flexible Environmental Salt Spray Machine for Quick Tests IE42 Series 270L 2.5KWatt
IE4290L  Flexible Environmental Salt Spray Machine for Quick Tests IE42 Series 270L 2.5KWatt
Product Details:
Place of Origin: Made In China
Brand Name: Infinity Machine
Certification: CE,ISO
Model Number: IE4290L
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD1000~100000 PC
Packaging Details: inner box size+ master carton size
Delivery Time: 15-25 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 30PC PER MONTH
Contact Now
Detailed Product Description
Laboratory Temperature Range: RT+5℃~60℃ Temperature Uniformity: ≦1.0℃
Box Structure: ●The Inner And Outer Boxes Of The Laboratory: The Inner And Outer Boxes Of The Laboratory Are Made Of Grade A PVC Polyvinyl Board, The Thickness Of The Whole Machine Is 8mm, And The Acid And Alkali Resistance And Temperature Resistance To 78℃. ●Laboratory Temperature Fluctuation: ±0.5℃
Interior Dimension: WxHxD(mm): 900*600*500 Spray Pressure: 1.00±0.01kgf/cm²
Pressure Barrel Temperature Range: RT+5℃~70℃ Carton Size: WxHxD(mm): 1400*850*1100
Capacity: 250L Humidity: 85%~98%RH
Temperature Range: ± 0.5℃ Salt Spray Subside: 1.0~2.0ml/80cm2/h
Test Room Size: 900x600x450mm Machine Size: 1460x910x1280mm
Lab Temperature: NSS.ACSS 35°C ± 1 °C / CASS 50°C ± 1 °C Saturator Temperature: NSS.ACSS 35°C ± 1 °C / CASS 50°C ± 1 °C
Power Supply: AC220V 15A Or Specified By User Water Way: Atered By Itself While Lack Of Water
Spray Work Time: Precise Spray Can Work 2000 Hours Without Crystalled Jam. Body Material: Japanese PVC Environmental Protection & High Anti-aging Capability
Spray Material: Transparent PVC SSR: Precisely Digital Thermal Controller With Spray Protection System.
Standards: GB/T5170.8, GB/T2423.17, ISO-3768 3769 3770, ASTM-B117 B268, JIS-D0201 H8502 H8610 K5400 Z2371 Application: This Tester Is Used For The Surface Erosion Resistance Test Of Kinds Of Material Processed By Paint, Plating, Anodized.

IE4290L Flexible Environmental Salt Spray Machine for Quick Tests IE42 Series 270L 2.5KWatt

IE4290L  Flexible Environmental Salt Spray Machine for Quick Tests IE42 Series 270L 2.5KWatt 0

Product Description:

IE4290L​ Salt Spray Machine is a type of environmental testing machine designed to simulates the dispersion system composed of tiny droplets of salt in the atmosphere. It is widely used in electroplating and spray painting of products in the electronics, electrical, automobile, motorcycle, hardware, plastic, FPC soft board, and other industries. , coatings, and anodic treatment before conducting a salt spray corrosion test to evaluate its surface corrosion resistance.


Applicable standards:
IE4290L  Flexible Environmental Salt Spray Machine for Quick Tests IE42 Series 270L 2.5KWatt 1 GB/T242317-2008
IE4290L  Flexible Environmental Salt Spray Machine for Quick Tests IE42 Series 270L 2.5KWatt 2 GB/T242318-2000
IE4290L  Flexible Environmental Salt Spray Machine for Quick Tests IE42 Series 270L 2.5KWatt 3 GB/T10125-1997
IE4290L  Flexible Environmental Salt Spray Machine for Quick Tests IE42 Series 270L 2.5KWatt 4 GB/T10587-2006
IE4290L  Flexible Environmental Salt Spray Machine for Quick Tests IE42 Series 270L 2.5KWatt 5 GB105932-1990
IE4290L  Flexible Environmental Salt Spray Machine for Quick Tests IE42 Series 270L 2.5KWatt 6 GB/T1765-1979
IE4290L  Flexible Environmental Salt Spray Machine for Quick Tests IE42 Series 270L 2.5KWatt 7 GB/T242317-1993
IE4290L  Flexible Environmental Salt Spray Machine for Quick Tests IE42 Series 270L 2.5KWatt 8 GB/T1771-2007
IE4290L  Flexible Environmental Salt Spray Machine for Quick Tests IE42 Series 270L 2.5KWatt 9 GB5938-86
IE4290L  Flexible Environmental Salt Spray Machine for Quick Tests IE42 Series 270L 2.5KWatt 10 GB/T1771-91



Technical Parameters:

Parameter Value

Model No.

IE4290L

Safety protection device ●When The Salt Water Is Low, The Heater Power Is Automatically Cut Off ●When The Temperature Exceeds, The Heater Power Supply Is Automatically Cut Off ●When The Laboratory Water Level Is Low, The Heater Power Supply Is Automatically Cut Off
Carton size WxHxD(mm):1400*850*1100
Water refill method Automatic/manual Dual Water Supply Mode, Automatic Water Inlet With A Set Of Water Purifier
Laboratory temperature range RT+5℃~60℃
Spray pressure 1.00±0.01kgf/cm²
Spray method Continuous Spray + Intermittent Spray
Model number

IE4290L

Open cover system Manual Opening.One-click Automatic Cover Opening
Interior dimension WxHxD(mm):900*600*500


Applications:

Are you looking for Flexible Environmental Salt Spray Machine? Look no further than Infinity Machine's IE4290L, the perfect environmental test system. Made in China, this model is both CE and ISO certified, making it one of the highest quality products on the market. This high and low temperature test chamber is powered by AC220V;50Hz;1.5KW, and has a laboratory temperature range of RT+5℃~60℃.

Customization:

Infinity Machine's Environmental Test Chamber:IE4290L

Brand Name: Infinity Machine
Model Number:IE4290L
Place of Origin: Made In China
Certification: CE,ISO
Laboratory temperature range: RT+5℃~60℃
Carton size: WxHxD(mm): 1050*700*950
Power Supply: AC220V;50Hz;1.5KW
Spray method: Continuous Spray + Intermittent Spray
Sample Stand: The Laboratory Basket Frame Adopts A Plane Indexing Frame, The Placing Angle Is 15 Degrees And 30 Degrees, And On All Sides The Direction Of Falling Fog And Receiving Fog Is Completely The Same.

Climate Test Chamber





Support and Services:

Environmental Test Chamber Technical Support and Service

We provide technical support and servicing for our Environmental Test Chambers.

  • Full installation and commissioning services
  • Calibration services and certification
  • Preventative maintenance
  • Onsite troubleshooting and repairs

Our technical support team has extensive knowledge and experience in all aspects of Environmental Test Chamber maintenance and servicing.
For more information about our technical support and servicing, please contact us.



Packing and Shipping:

Packaging and Shipping of Environmental Test Chamber:
The environmental test chamber should be packaged in secure and secure materials, such as bubble wrap and cardboard. Once packaged securely, the chamber should be placed in a wooden crate for additional protection. The crate should be clearly labeled with the product description, weight, and sender/receiver information. All crates should be clearly labeled with "Fragile" to ensure careful handling during transit.
The test chamber should be shipped using a reliable and reputable shipping company, such as UPS or FedEx, and insured for the full value. The chamber should be shipped via ground transportation and should be monitored for its entire journey.



FAQ:

Q1: What is Environmental Test Chamber?

A1: Environmental Test Chamber is a device used to test the performance of products under certain environmental conditions, such as temperature, humidity and pressure. Infinity Machine's Environmental Test Chamber, model IE4260L, is made in China and is certified with CE and ISO standards.

Q2: What are the features of Infinity Machine's Environmental Test Chamber?

A2: Infinity Machine's Environmental Test Chamber, model IE4260L, is designed with advanced temperature control system, excellent temperature uniformity and high-precision temperature control accuracy. It is also equipped with a reliable data recording system, which can help you collect testing data in a timely and accurate manner.

Q3: What is the temperature range of Infinity Machine's Environmental Test Chamber?

A3: The temperature range of Infinity Machine's Environmental Test Chamber, model IE4260L, is -70℃ to +180℃.

Q4: What is the capacity of Infinity Machine's Environmental Test Chamber?

A4: The capacity of Infinity Machine's Environmental Test Chamber, model IE4260L, is 608 liters.

Q5: Does Infinity Machine's Environmental Test Chamber have a heating/cooling system?

A5: Yes, Infinity Machine's Environmental Test Chamber, model IE4260L, is equipped with a powerful heating and cooling system, which can provide fast and stable temperature control.
