| Place of Origin: | MADE IN CHINA |
| Brand Name: | INFINITY |
| Certification: | CE ISO |
| Model Number: | IE 42 Series |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Clear sheet+sponge+wood carton |
| Delivery Time: | 20-30 days after order confirmed |
| Payment Terms: | TT PAYPAL Moneygram and so on |
| Supply Ability: | 200 sets / month |
| Open Cover Way: | Manual Open Cover & One-click Automatic Open-cover | Application: | It Is Also Suitable For Accelerated Corrosion Tests, Such As Metals And Their Alloys, Metal Overlays (anodic And Cathodic), Conversion Overlays, Anodic Overlays, Organic Overlays On Metal Materials, Etc. |
|---|---|---|---|
| Box Structure: | ● Test Room And Outer Box: The Inner And Outer Box Of The Laboratory Adopts A Class PP Polyethylene Dilute Board, The Thickness Of The Whole Machine Is 10mm, Acid And Base Resistance And Temperature Resistance To 90℃. ● Laboratory Sealing Cover: Laboratory | Water Filling Methods: | Automatic / Manual Dual Water Supply Mode, Automatic Water Inlet With A Set Of Water Purifier |
| Spray Way: | Continuous Spray + Intermittent Spray | Salt Mist Settlement: | 1～3ml/h.80cm2 |
| Pressure Barrel Temperature Range: | RT+5℃~70℃ | Temperature Fluctuation: | ±0.5℃ |
15mm Surround Reinforcement Salt Spray Corrosion Test Chamber for High Humidity Range IE42
The Environmental Salt Spraying Tester, also known as the Salt Spray Testing Machine or Salt Spray Fog Test Chamber, is a specialized equipment used for testing the corrosion resistance of various materials and coatings under simulated salt spray environment. It is widely used in industries such as automotive, aerospace, electronics, and metal finishing.
Models: The Salt Spray Test Chamber (New) is available in 5 different models to meet the diverse testing needs of different industries:
| Model | Description |
|---|---|
| I E4260L | 60L capacity, suitable for small scale testing |
| I E4290L | 90L capacity, suitable for medium scale testing |
| I E42120L | 120L capacity, suitable for large scale testing |
| I E42160L | 160L capacity, suitable for extra large scale testing |
| I E42200L | 200L capacity, suitable for heavy duty testing |
Humidity Range: The Salt Spray Test Chamber (New) offers a humidity range of 20~100%R.H, making it suitable for simulating various salt spray environments.
Specimen Holder: In the laboratory, the placement frame adopts the plane dividing frame, allowing for easy placement of the test samples. The placement angle of 15 degrees and 30 degrees is optional, providing flexibility in testing different types of materials. The fog on all sides and the fog direction is completely consistent, ensuring accurate and uniform testing results.
Safety Protection Devices: The Salt Spray Test Chamber (New) is equipped with multiple safety protection devices to ensure safe and reliable testing:
Temperature Uniformity: The Salt Spray Test Chamber (New) has a temperature uniformity of ≦1.0℃, ensuring consistent and precise testing results.
| Model | I E4260L | I E4290L | I E42120L | I E42160L | I E42200L | |
| Laboratory Temperature Range | RT+5℃~60℃ | |||||
| Pressure Barrel Temperature Range | RT+5℃~70℃ | |||||
| Temperature Fluctuation | ±0.5℃ | |||||
| Temperature Uniformity | ≦1.0℃ | |||||
| Salt Mist Settlement | 1～3ml/h.80cm2 | |||||
| Spray Pressure | 1.00±0.01kgf/cm² | |||||
| Spray Way | Continuous spray + intermittent spray | |||||
| Valid Capacity for Testing | 150L | 270L | 576L | 800L | 1200L | |
|
WxHxD(mm ) |
600*450*400 | 900*600*500 | 1200*800*600 | 1600*1000*500 | 2000*1000*600 | |
|
Out box size: WxHxD(mm ) |
1050*700*950 | 1400*850*1100 | 2080*1050*1300 | 2430*1250*1400 | 2830*1250*1400 | |
| Box structure |
● Laboratory sealing cover: laboratory sealing cover adopts A class PP plate, thickness of 10mm, surround reinforcement of 15mm, acid and base resistance and temperature resistance of 90℃ |
|||||
| Open cover way | Manual open cover | One-click automatic open-cover | ||||
| Water filling methods | Automatic / manual dual water supply mode, automatic water inlet with a set of water purifier | |||||
| Specimen holder | In the laboratory, the placement frame adopts the plane dividing frame, the placement Angle of 15 degrees and 30 degrees is optional, and the fog on all sides and the fog direction is completely consistent. | |||||
| Safety protection devices |
● When low brine, automatically cut off the heater power supply. ● Over-temperature, automatically cut off the heater power supply. ● When the laboratory is at low water level, automatically cut off the heater power supply. |
|||||
| Power | AC220V;50Hz;1.5KW | AC 220;V50Hz;2.5KW | AC 220;V50Hz;3.5KW | AC 220;V50Hz;4.5KW | AC 380;V50Hz;5KW | |
Our brand new Salt Spray Test Chamber is the perfect solution for testing the corrosion resistance of electrical and electronic products. Designed and manufactured by INFINITY, a leading company in environmental testing equipment, this salt spray testing machine is the ideal choice for various industries.
The IE 42 Series Salt Spray Test Chamber is proudly made in China and has obtained CE and ISO certification, ensuring high quality and reliability. With a minimum order quantity of just 1 unit, we offer competitive pricing and flexible payment terms such as TT, PayPal, and Moneygram. Our packaging consists of a clear sheet, sponge, and wood carton for safe transportation, and we guarantee a delivery time of 20-30 days after order confirmation. Our supply ability is 200 sets per month, making us a reliable and efficient supplier for your testing needs.
Our Salt Spray Test Chamber complies with several industry standards, including GB / T242317-2008, GB / T242318-2000, GB / T10125-1997, GB / T10587-2006, GB105932-1990, GB / T1765-1979, GB / T242317-1993, GB / T1771-2007, GB5938-86, and GB / T1771-91. These standards cover basic procedures for testing electrical and electronic products, corrosion resistance, artificial atmosphere corrosion, salt spray testing technical conditions, environmental parameter measurements, and more.
The temperature range of our Salt Spray Test Chamber is RT+5℃~60℃, making it suitable for a wide range of testing requirements.
Our Salt Spray Test Chamber comes equipped with various safety protection devices, including automatic cut off of heater power supply in case of low brine or over-temperature, and automatic cut off of heater power supply when the laboratory is at a low water level.
The salt mist settlement rate of our chamber is 1～3ml/h.80cm2, providing accurate and reliable results for your testing needs.
In the laboratory, the placement frame adopts a plane dividing frame with optional placement angles of 15 degrees and 30 degrees. The fog on all sides and the fog direction is completely consistent, ensuring consistent and accurate results.
Our Salt Spray Test Chamber can be used in various industries, including electronics, automotive, aerospace, and more. It is ideal for testing the corrosion resistance of products such as PCBs, electronic components, automotive parts, and coatings. With its compact design and user-friendly interface, our chamber is suitable for both laboratory and production line use. Its accurate and reliable results make it an essential tool for quality control and product development.
Experience the reliability and efficiency of our Salt Spray Test Chamber by ordering now. Contact us to negotiate the price and discuss your testing needs. With our superior quality and excellent customer service, we guarantee your satisfaction with our product. Choose INFINITY for all your environmental testing equipment needs.
We offer specialized customization services for our Salt Spray Test Chamber (New) to meet your specific needs and requirements.
Our brand, INFINITY, guarantees high quality and reliable performance for our IE 42 Series model.
As a product of China, our Salt Spray Test Chamber (New) is certified with CE and ISO standards.
We have a low minimum order quantity of just 1 unit and our price is negotiable.
The packaging for our Salt Spray Test Chamber (New) includes a clear sheet, sponge, and wooden carton for secure transportation.
With a delivery time of 20-30 days after order confirmation, we offer flexible payment terms such as TT, PayPal, Moneygram, and more.
Our supply ability is 200 sets per month, ensuring prompt delivery for our customers.
The spray pressure of our Salt Spray Test Chamber (New) is 1.00±0.01kgf/cm², meeting industry standards for accurate testing.
Our equipment is designed to meet various international test standards such as GB / T242317-2008, GB / T242318-2000, GB / T10125-1997, GB / T10587-2006, GB105932-1990, GB / T1765-1979, GB / T242317-1993, GB / T1771-2007, GB5938-86, and GB / T1771-91.
Our Salt Spray Test Chamber (New) is available in different power options: About 300, About 400, About 500, About 600, and About 700.
We prioritize safety and have equipped our equipment with safety protection devices such as automatic cut-off for low brine, over-temperature, and low water level in the laboratory.
The design principle of our Salt Spray Test Chamber (New) is to simulate the atmosphere salt droplets diffusion system, making it suitable for testing corrosion resistance of various products in industries such as electronics, electrician, automobile, motorcycle, hardware, plastic, FPC soft board, and more.
Choose INFINITY for a reliable and customized Salt Spray Test Chamber (New) experience.
Our salt spray test chamber comes with strong and durable packaging to ensure safe delivery to our customers. Each unit is carefully packed and shipped to prevent any damage during transit.
The chamber is placed in a sturdy wooden crate and securely fastened to prevent any movement during shipping. The wooden crate is then wrapped with protective packaging materials such as bubble wrap and foam to provide an additional layer of protection.
The package is then labeled with clear instructions and handling precautions to ensure proper handling and installation. We also provide detailed installation and operation manuals for our customers to easily set up the chamber upon delivery.
Our chambers are shipped via reliable and trusted freight carriers to ensure timely and safe delivery. We offer both air and sea shipping options, depending on the customer's preference and urgency of delivery.
We take great care in packaging and shipping our salt spray test chambers to ensure that they arrive at our customer's doorstep in perfect condition.
