Sand And Dust Test Chamber Vibration Time 0-999999S 60L/H Adjustable

Sand And Dust Test Chamber Vibration Time 0-999999S 60L/H Adjustable

  • Sand And Dust Test Chamber  Vibration Time 0-999999S 60L/H Adjustable
  • Sand And Dust Test Chamber  Vibration Time 0-999999S 60L/H Adjustable
Sand And Dust Test Chamber  Vibration Time 0-999999S 60L/H Adjustable
Product Details:
Place of Origin: Made In China
Brand Name: Infinity Machine
Certification: CE, ISO
Model Number: IE 7 Series
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard export wooden case with operation manual and video inside.
Delivery Time: Shipped in 15 days after payment
Payment Terms: T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability: 200 sets per month
Contact Now
Detailed Product Description
Powder Spraying And Dust Reduction Method:: Free Dust Fall Vibration Time:: 0-999999S(adjustable)
Total Test Time:: 0-999999min(adjustable) Standard Dosage Of Talc Powder:: 2~4kg/m³
Pumping Speed:: 0-60L/H(adjustable) Interior Dimension :(mm)(W*D*H): 800*800*800 Customizable
Timing Accuracy:: ±1 Second Product Name: Sand And Dust Test Chamber
High Light:

Sand And Dust Test Chamber

,

Dust Test Chamber 60L/H

Sand And Dust Test Chamber Product Model IE7 Series Vibration Time 0-999999S(Adjustable)

Sand And Dust Test Chamber



Product Model :IE7 series

Sand And Dust Test Chamber  Vibration Time 0-999999S 60L/H Adjustable 0



Product Description And Applications:



The main function of this equipment is to test the physical and other related properties of electronic and electrical products, lamps, electrical cabinets, electrical components, automobiles, motorcycles and their parts under simulated dust climate conditions. After testing, verification is used to determine whether the performance of the product meets the requirements, so as to facilitate product design, improvement, verification and factory inspection

Features:

1. Suitable for IP5X and IP6X dustproof grade testing of products.

2. The shell is made of domestic high-quality steel plates, and the surface is spray-painted, making it beautiful and durable.

The inner box, sample rack, etc. are all made of stainless steel plates to ensure that they will not rust after long-term use.

3. There is a transparent observation window (made of tempered glass) on the door, and LED lighting is installed inside the box to facilitate observation of internal testing conditions.

4. There is a dust-replaceable device at the bottom of the equipment, which can easily replace used dust.

5. There is a vibration device installed in the box, which can automatically work alternately to prevent dust from sticking to the box wall and condensation.

6. There is an air extraction tube inside the box, which can complete the vacuuming action on the sample (exhaust holes need to be reserved for the sample)

7. There is an air extraction tube inside the box, which can complete the vacuuming action on the sample (exhaust holes need to be reserved for the sample).

Sand and dust test chamber control system: adopts 7-inch touch screen + Panasonic PLC, which can display the year, month, day, time, working hours, etc. The dust blower, dust vibration and total test time can be controlled separately; this controller has a variety of arbitrary setting control functions as follows;

a. Dust blowing time (stop, blow): Continuous or periodic dust blowing can be set at any time;

b. Vibration time: vibration and stop vibration times are automatically alternated;

c. Preset test time: The test time range is 0-999999 minutes;

d. Power on: off - on - off.



8. Heating system: A heater is installed in the circulating air duct to avoid dust condensation, and the pipe-wrapped mica sheet heating ring ensures safe and stable heat;

9. Vacuum system: Equipped with vacuum pump, vacuum gauge, air filter, flow meter, and connecting pipes



Technical Parameters:

Items

Specification

Interior dimension :(W*D*H)

800*800*800mm(customizable)

External dimensions:(W*D*H)

1250*1050*1755mm(customizable)

Metal screen standard wire diameter:

50um

Standard spacing between lines:

75um

Standard dosage of talc powder:

2~4kg/m³

Test dust:

Arizona DUST A2 (standard 2Kg)

Powder spraying and dust reduction method:

Free dust fall

Total test time:

0-999999min(adjustable)

Vibration time:

0-999999S(adjustable)

Timing accuracy:

±1 second

Vacuum gauge range:

0—10Kpa(adjustable)

Pumping speed:

0-60L/H(adjustable)

Security protection function:

Leakage protection, short circuit protection

Power supply for test samples:

220V(or specify)

Equipment power:

220V 50Hz 1.5KW(or specify)





Support and Services:

Technical Support and Service for Sand And Dust Test Chamber

Thank you for choosing our Sand And Dust Test Chamber . We are dedicated to providing high-quality products and excellent customer service. In order to ensure that your product operates at its best performance, we offer the following technical support and services:

Installation and Setup:

Our team of experienced technicians will provide you with on-site installation and setup support to ensure that your Sand And Dust Test Chamber is properly installed and configured according to your specific needs.

Training:

We offer comprehensive training sessions for your staff on how to use and maintain the Sand And Dust Test Chamber . This will enable you to maximize the efficiency and effectiveness of the product.

Calibration and Maintenance:

We offer regular calibration and maintenance services to ensure that your Sand And Dust Test Chamber is always accurate and functioning properly. Our team will also provide you with recommendations for any necessary repairs or replacements.

Technical Support:

If you encounter any technical issues with your Sand And Dust Test Chamber , our team of experts is available to provide you with prompt and efficient technical support. You can reach us through phone, email, or online chat.

Upgrades and Customization:

We understand that your testing needs may change over time. Therefore, we offer upgrade options and customization services to meet your evolving requirements.

Warranty:

Our Sand And Dust Test Chamber comes with a comprehensive warranty to ensure your satisfaction and peace of mind. Please refer to your product manual for more details.

Thank you for choosing our Sand And Dust Test Chamber . We are committed to providing you with the best technical support and services. If you have any further questions or concerns, please do not hesitate to contact us.



Packing and Shipping:

Packaging and Shipping of Sand And Dust Test Chamber

Our Sand And Dust Test Chamber  is carefully packaged to ensure safe and secure delivery to our customers. We understand the importance of protecting delicate equipment during shipping, and our packaging materials are designed to provide maximum protection against any potential damage.

The Sand And Dust Test Chamber is first wrapped in a layer of protective bubble wrap to prevent any scratches or dings during transit. It is then placed in a sturdy cardboard box or wooden box, which is specially designed to withstand the rigors of shipping. The box is sealed with strong tape to ensure that the contents remain secure throughout the journey.

In addition to the protective packaging, we also include clear instructions for assembly and use of the Sand And Dust Test Chamber. This ensures that our customers are able to easily set up and use the product upon arrival.

We offer a variety of shipping options to meet our customers' needs. Our standard shipping method is via ground transportation, but we also offer expedited shipping for those who need their orders to arrive quickly. Our shipping rates are calculated based on the weight and dimensions of the package, as well as the destination address.

We take great care in ensuring that our Sand And Dust Test Chamber arrives in perfect condition to our customers. In the unlikely event of any damage during shipping, please contact our customer service team for assistance.



FAQ:

  • Q: What is the brand name of this product?
    A: The brand name of this product is Infinity Machine.
  • Q: What is the model number of this product?
    A: The model number of this product is IE 7 Series.
  • Q: Where is this product made?
    A: This product is made in China.
  • Q: What certifications does this product have?
    A: This product is certified with CE and ISO.
  • Q: What is the minimum order quantity for this product?
    A: The minimum order quantity for this product is 1.
  • Q: How is this product packaged?
    A: This product is packaged in master cartons and wooden box.
  • Q: What is the delivery time for this product?
    A: The delivery time for this product is 200 sets per month.
  • Q: What are the payment terms for this product?
    A: The payment terms for this product are T/T, D/P, and L/C.
