Programmable Composite Salt Spray Test Chamber IE4090L High Accuracy

Programmable Composite Salt Spray Test Chamber IE4090L High Accuracy

  • Programmable Composite Salt Spray Test Chamber IE4090L High Accuracy
  • Programmable Composite Salt Spray Test Chamber IE4090L High Accuracy
Programmable Composite Salt Spray Test Chamber IE4090L High Accuracy
Product Details:
Place of Origin: Made In China
Brand Name: Infinity Machine
Certification: CE, ISO
Model Number: IE4090L
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard export wooden case with operation manual and video inside.
Delivery Time: Shipped in 15 days after payment
Payment Terms: T/T, Western Union, D/A, D/P, MoneyGram
Supply Ability: 200 sets per month
Contact Now
Detailed Product Description
Humidity Range: 20~100%R.H Refrigeration Compressor: France Taikang Fully Closed Compressor
Coolants: Non-fluorine Environmental Refrigerant R404A Complies With Environmental Regulations And Is Safe And Non-toxic Temperature Deviation: ±1℃
Test Effective Inner Volume: 270L Sample Stand: The Inner Wall Of The CPVC Polyvinyl Triangle Box Is Placed On The Index Frame, And The Angle Of The Test Product Can Be Adjusted Arbitrarily, And The Number Of Test Pieces Is Completely Consistent In The Four Sides Falling Fog And Receiving Fog. CPVC Plat
Weight(Kg): About 400 Temperature Uniformity: ≦2.0℃
Capacity: 250L Humidity: 85%~98%RH
Temperature Range: ± 0.5℃ Salt Spray Subside: 1.0~2.0ml/80cm2/h
Test Room Size: 900x600x450mm Machine Size: 1460x910x1280mm
Lab Temperature: NSS.ACSS 35°C ± 1 °C / CASS 50°C ± 1 °C Lab Temperature: NSS.ACSS 35°C ± 1 °C / CASS 50°C ± 1 °C
Lab Temperature: NSS.ACSS 35°C ± 1 °C / CASS 50°C ± 1 °C Saturator Temperature: NSS.ACSS 35°C ± 1 °C / CASS 50°C ± 1 °C
Power Supply: AC220V 15A Or Specified By User Water Way: Atered By Itself While Lack Of Water
Spray Work Time: Precise Spray Can Work 2000 Hours Without Crystalled Jam. Body Material: Japanese PVC Environmental Protection & High Anti-aging Capability
Spray Material: Transparent PVC SSR: Precisely Digital Thermal Controller With Spray Protection System.
SSR: Precisely Digital Thermal Controller With Spray Protection System. SSR: Precisely Digital Thermal Controller With Spray Protection System.
Standards: GB/T5170.8, GB/T2423.17, ISO-3768 3769 3770, ASTM-B117 B268, JIS-D0201 H8502 H8610 K5400 Z2371 Standards: GB/T5170.8, GB/T2423.17, ISO-3768 3769 3770, ASTM-B117 B268, JIS-D0201 H8502 H8610 K5400 Z2371
Application: This Tester Is Used For The Surface Erosion Resistance Test Of Kinds Of Material Processed By Paint, Plating, Anodized.
High Light:

Composite Salt Spray Test Chamber

,

High Accuracy Salt Spray Test Chamber



Programmable Composite Salt Spray Test Chamber



Model Number:IE4090L



Programmable Composite Salt Spray Test Chamber IE4090L High Accuracy 0





Product Description and Applications:

The Programmable Composite Salt Spray Test Chamber is designed to simulate and increase the environmental effects on metal materials exposed to outdoor atmosphere with salt contamination and accelerated corrosion. The equipment includes test methods for cyclic exposure of samples to salt spray, dry, humid and hot environments. The test of this equipment is a comparative test, and the test results cannot predict the long-term corrosion resistance of the same metal materials used in this environmental condition. However, this method can still provide valuable information about the properties of materials exposed to salt contamination under conditions similar to those tested. Compared with the traditional accelerated corrosion test, such as neutral salt spray test (NSS), acetic acid salt spray test (AASS), copper accelerated acetic acid salt spray test (CASS), the biggest advantage of this device test is that it can better reproduce the corrosion occurring in outdoor salt pollution environment.

At the same time, it is suitable for accelerated corrosion tests, such as metals and their alloys, metal coatings (anodic and negative polarity), conversion coatings, anodic oxidation coatings, organic coatings on metal materials, etc.





Features:

  • It can be specially designed according to different customer needs.
  • PT100 temperature sensor with high accuracy and low maintenance.
  • According to the customer installation site can be manually and automatically add water, easy to use.
  • The greenhouse and the laboratory are independent, and the middle is connected through the damper control, which has perfect structure and easier maintenance.
  • Energy-saving design, separate control according to different tests.
  • It can do neutral salt spray test, corrosion resistance test, dry test, wet test, static test, but also can do salt spray, dry and wet, static mixing test, automatic control.
  • Automatic periodic spray, continuous spray, timed spray.
  • No need to move the product, you can realize the salt spray, wet heat, dry automatic cycle test, easy to use





Technical Parameters:



Parameters

Details

 Model number

 IE4090L

 Temperature range

 0℃ ~ +90℃

 Temperature deviation

 ±1℃

 Temperature fluctuation

 ±0.5℃

 Temperature uniformity

 ≦2.0℃

 Humidity range

 20~100%R.H

 Humidity deviation

 ±2%R.H

 Humidity fluctuation

 ±2%R.H

 Humidity uniformity

 ±3%R.H

 Temperature and humidity range



Programmable Composite Salt Spray Test Chamber IE4090L High Accuracy 1





 Rate of heating and cooling

 RT→+95℃≤50 min.

 RT→+0℃≤30 min

 Salt spray (35℃)→ drying (60℃.20~30%RH)≤30 min.

 Drying (60℃,20~30%RH)→ wetting (50℃,95%+/-5%RH)≤15 min.

 Wetting (50℃,95%+/-5%RH)→ salt spray (35℃)≤30 min(immediately spray after switching).

 Test effective inner volume



 270L

 Interior dimension:WxHxD(mm)

 900*600*600

 Carton size:WxHxD(mm)

 2080*1050*1350

 Box structure



 Test chamber: imported CPVC polyethylene plate, thickness 8mm, temperature resistance of about   120 degrees.

 Outdoor test box: imported CPVC polyethylene plate, thickness 8mm, temperature resistance of   about 120 degrees.

 Laboratory seal cover: imported CPVC polyethylene plate, thickness 8mm, one-button automatic   opening cover, with transparent observation window, combined with fog removal device,

 Convenient for clear observation of the test during the test, temperature resistance of about 120   degrees.

 Water refill method

    Automatic/manual dual water supply mode, automatic water inlet with a set of water purifier

 Sample Stand

The inner wall of the CPVC polyvinyl triangle box is placed on the index frame, and the Angle of the test product can be adjusted arbitrarily, and the number of test pieces is completely consistent in the four sides falling fog and receiving fog.

CPVC plate punching sample placement platform is set at the bottom of the test chamber. The uniform opening on the surface of the platform will quickly discharge the spray liquid, and large samples can be placed on the table for testing.

 Refrigeration compressor

   France Taikang fully closed compressor

 Coolants

   Non-fluorine environmental refrigerant R404A complies with environmental regulations and is           safe and non-toxic

 Condenser system

Air-cooled



 Safety protection device



 Refrigeration System

 Compressor overheat protection

 Compressor overcurrent protection

 Compressor overpressure, low pressure protection

 Condensate fan overheat protection

 Test Chamber

 Adjustable overtemperature protection alarm

 Air conditioning channel limit overtemperature protection

 Fan, motor overheat relay protection

 Heating System

 Heating tube dry burning protection

 Abnormal water supply alarm

 Abnormal drainage alarm

 Other

 Earth leakage protection

 Overload and short circuit protection

 The power supply lacks reverse phase protection function

 Weight(Kg)

 About 400

 Power supply

 AC380;V50Hz;9KW

ApplicableStandard:

  • GB/T20854-2007/ISO14993-2001 Wet and dry salt spray test.
  • GB-T5170.8-2008_test method for environmental test equipment for electrical and electronic products___ Salt spray test equipment.
  • GJB150.11A-2009 Military equipment laboratory environmental test method salt spray test.
  • GBT2424.17-2008 salt spray test method.
  • GB-T2423.18-2000 Alternating salt spray test method for sodium chloride.
  • GB-T2423.3-2006 (IEC6008-2-78-2001) test cab: constant wet heat test method.
  • GBT2423_4-2008 test method for alternating humidity and heat.
  • IEC 60068-2-52-2017 Environmental tests-Part 2-25 Test Kb Cyclic salt spray (sodium chloride solution).
  • IEC 60068-2-11-1982 Electrical Appliance Technology. Basic environmental test procedures. Part 2: Testing. Section 11: Test Ka: Salt spray.









Support and Services:



Programmable Composite Salt Spray Test Chamber Technical Support and Service

 Infinity company provide full technical support and service for ourProgrammable Composite Salt Spray Test Chamber.

Technical Support

We understand the importance of having reliable equipment that meets your specifications and needs. That’s why our team of professionals are available to answer your questions and provide technical assistance. We provide support via phone, email, and online chat. Our goal is to help you find the most suitable product for your application.

Service

Our service team stands ready to help you with any repairs, maintenance, and calibration of your test chamber. Our technicians are certified and experienced in working with Programmable Composite Salt Spray Test Chamber. We are committed to providing fast and reliable service to ensure your chamber is up and running in no time.



Packing and Shipping:



Packaging and Shipping for Programmable Composite Salt Spray Test Chamber:

  • Programmable Composite Salt Spray Test Chamber should be packed in sturdy, vibration-proof containers.
  • The container should be large enough to ensure that the Environmental Test Chamber is securely and safely packed.
  • The container should have a cushioning material to absorb shock during transportation.
  • Before shipping, the Programmable Composite Salt Spray Test Chamber should be inspected to make sure that it is in good condition.
  • If any damage is found, it should be reported to the manufacturer before shipping.
  • The Programmable Composite Salt Spray Test Chamber should be shipped according to the instructions provided by the manufacturer.
