9KW High And Low Temperature Test Chamber Heating Rate -40C-100C Within 60s No Load

9KW High And Low Temperature Test Chamber Heating Rate -40C-100C Within 60s No Load

  • 9KW High And Low Temperature Test Chamber Heating Rate -40C-100C Within 60s No Load
  • 9KW High And Low Temperature Test Chamber Heating Rate -40C-100C Within 60s No Load
9KW High And Low Temperature Test Chamber Heating Rate -40C-100C Within 60s No Load
Product Details:
Place of Origin: Made In China
Brand Name: Infinity Machine
Certification: CE, ISO
Model Number: IE10800L
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard export wooden case with operation manual and video inside.
Delivery Time: Shipped in 15 days after payment
Payment Terms: T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability: 200 sets per month
Contact Now
Detailed Product Description
Humidity Uniformity: ± 3.0% RH (no Load) Power Supply: AC220V 15A Or Specified By User
Carton Size : WxHxD(mm): 1220×1940 ×1620 Temperature Range: ± 0.5℃
Warm Box: ● External Wall Material: High Quality Carbon Steel Plate, Surface For Electrostatic Color Spray Treatment. The Left Side Of The Box Is φ50mm Diameter Hole.● Inner Wall Material :SUS304# Stainless Steel Plate.● Insulation Material: Hard Polyurethane Foam I Humidity Control Range: 20%R.H~98%R.H
Humidity Fluctuation: ±1.0%RH Temperature Fluctuation: ±0.5℃
Capacity: 250L Humidity: 85%~98%RH
Salt Spray Subside: 1.0~2.0ml/80cm2/h Test Room Size: 900x600x450mm
Machine Size: 1460x910x1280mm Lab Temperature: NSS.ACSS 35°C ± 1 °C / CASS 50°C ± 1 °C
Saturator Temperature: NSS.ACSS 35°C ± 1 °C / CASS 50°C ± 1 °C Water Way: Atered By Itself While Lack Of Water
Spray Work Time: Precise Spray Can Work 2000 Hours Without Crystalled Jam. Body Material: Japanese PVC Environmental Protection & High Anti-aging Capability
Spray Material: Transparent PVC SSR: Precisely Digital Thermal Controller With Spray Protection System.
Standards: GB/T5170.8, GB/T2423.17, ISO-3768 3769 3770, ASTM-B117 B268, JIS-D0201 H8502 H8610 K5400 Z2371 Application: This Tester Is Used For The Surface Erosion Resistance Test Of Kinds Of Material Processed By Paint, Plating, Anodized.
High Light:

9KW Temperature Test Chamber

,

AC380V Temperature Test Chamber



Programmable Constant Temperature And Humidity Test Chamber





Model:IE10 800L9KW High And Low Temperature Test Chamber Heating Rate -40C-100C Within 60s No Load 0

Product Description:

Environmental Test Chamber is an high and low temperature test equipment used in various scientific research fields. It is designed to provide a range of testing environments with precise temperature control. This test chamber is powered by AC380V, 50Hz, 9KW, and its heating rate can reach from -40℃ to +100℃ within 60 minutes (no load, ambient temperature +25℃). The external wall material of the warm box is made of high quality carbon steel plate with electrostatic color spray treatment. The left side of the box also features a φ50mm diameter hole. The inner wall material is SUS304# stainless steel plate and the insulation material is hard polyurethane foam insulation layer plus glass fiber. The temperature fluctuation in the test chamber is ±0.5℃ and its interior dimension is WxHxD (mm): 1000×1000×800. This Environment Test Chamber is suitable for many industries, including electronics, electrical, automotive, chemical, aerospace, medical and other fields. It is an ideal testing device for environmental testing and testing of electronic and electrical products.



Features:

  • Environmental Test Chamber: Aging Test Chamber
  • Carton size: WxHxD(mm): 1220×1940 ×1620
  • Lighting device: 1 LED Lighting Device, Installed On The Window.
  • Temperature range: -40℃ ~ +150℃
  • Inspection window: The W 300×H 400mm Observation Window Is Installed On The Door Of The Box, And Multi-layer Hollow Electrothermal Coated Glass Can Effectively Keep Heat And Prevent Condensation.
  • Humidity control range: 20%R.H~98%R.H


Technical Parameters:

Parameter Detail
Humidity control range 20%R.H~98%R.H
Humidity deviation ±3.0%RH(>75%RH) ±5.0%RH(≤75%RH)
Sample Stand Stainless Steel Sample Rack 2 Layers, Height Adjustable, Bearing Weight 30kg/ Layer.
Interior dimension WxHxD(mm): 1000×1000×800
Box door For A Single Door, Install A Heating Wire In The Door Frame To Prevent Condensation In The Door Frame At Low Temperature
Cooling rate From +20℃ To -40℃ Within 60min (no Load, Ambient Temperature +25℃)
Temperature fluctuation ±0.5℃
Power supply AC380;V50Hz;9KW
Safety protection device Heater Anti-burning Protection; Humidifier Anti-burn Protection; Heater Overcurrent Protection; Humidifier Overcurrent Protection; Circulating Fan Overcurrent Overload Protection; Compressor High Pressure Protection; Compressor Overheat Protection; Compressor Overcurrent Protection; Overvoltage Underinverse-phase Protection; Circuit Breaker; Leakage Protection; Humidifier Low Water Level Protection; Tank Low Water Level Warning.
Heating rate From -40℃ To +100℃ Within 60min (no Load, Ambient Temperature +25℃)


Applications:

Environmental Test Chamber from Infinity Machine (Model Number: IE10800L) is a top-notch environmental testing equipment that is made in China. It features France Taikang Fully Closed Compressor and Programmable Constant Temperature And Humidity Test Box, which provides excellent temperature uniformity of ≦2.0℃. With the interior dimension of WxHxD(mm): 1000×1000×800, it is perfect for many different testing environments. And it uses Non-fluorine Environmental Refrigerant R404A, which is in line with environmental regulations and safe and non-toxic. Environmental Test Chamber from Infinity Machine is perfect for commercial and industrial environmental testing and will provide reliable and accurate results.



Customization:

Infinity Machine's IE10800L Environmental Test Chamber is made in China. It has an outstanding humidity uniformity of ± 3.0% RH (no Load), and a temperature fluctuation of ±0.5℃. It is equipped with a LED lighting device, installed on the window. Its temperature range is -40℃ ~ +150℃. Moreover, it uses Non-fluorine Environmental Refrigerant R404A, in line with environmental regulations, safe and non-toxic. This product is perfect for Aging Test Chamber, Climate Test Chamber or Aging Test Chamber.



Support and Services:

Environmental Test Chamber Technical Support and Service

At ABC, we understand that our customers rely on our Environmental Test Chambers to provide reliable and accurate data that is critical to their success. We are committed to providing our customers with the highest level of service and technical support.

Technical Support

Our team of experienced engineers and technicians are available to answer any technical questions you may have regarding the operation and maintenance of your Environmental Test Chamber. We provide technical support over the phone, email, and online chat.

Service and Repairs

ABC offers service and repair plans to ensure that your Environmental Test Chamber is operating at peak performance. Our team of experienced technicians can provide on-site maintenance, repair, and calibration services. We also offer preventative maintenance plans to ensure that your equipment is running optimally and that all safety and compliance standards are met.



Packing and Shipping:

Packaging and Shipping of Environmental Test Chamber

Our Environmental Test Chamber is packaged in a strong and durable packaging material, which ensures that it is safe from any external damages during transportation. The packaging also has an anti-moisture layer to protect the instrument from moisture.

The shipping of our Environmental Test Chamber is done through reliable and professional shipping agents. The chamber is securely placed inside the packaging material and is then loaded in a vehicle for transportation. We ensure prompt and timely delivery of the product.



FAQ:

Q: What is Environmental Test Chamber?
A: Environmental Test Chamber (or climatic chamber) is a laboratory simulation device that reproduces the climate conditions required for product testing.
Q: What brand and model of Environmental Test Chamber does Infinity Machine offer?
A: Infinity Machine offers Environmental Test Chamber with Brand Name Infinity Machine and Model Number IE10800L.
Q: Where is Infinity Machine Environmental Test Chamber made?
A: Infinity Machine Environmental Test Chamber is made in China.
Q: What is the temperature range of Infinity Machine Environmental Test Chamber?
A: The temperature range of Infinity Machine Environmental Test Chamber is -70°C to +180°C.
Q: What is the warranty period of Infinity Machine Environmental Test Chamber?
A: Infinity Machine Environmental Test Chamber comes with a one-year warranty.
