1Kgf 2Kgf 300mm Micro Drop Testing Machine For Mobile Phone

1Kgf 2Kgf 300mm Micro Drop Testing Machine For Mobile Phone

  • 1Kgf 2Kgf 300mm Micro Drop Testing Machine For Mobile Phone
  • 1Kgf 2Kgf 300mm Micro Drop Testing Machine For Mobile Phone
  • 1Kgf 2Kgf 300mm Micro Drop Testing Machine For Mobile Phone
  • 1Kgf 2Kgf 300mm Micro Drop Testing Machine For Mobile Phone
1Kgf 2Kgf 300mm Micro Drop Testing Machine For Mobile Phone
Product Details:
Place of Origin: Made in China
Brand Name: Infinity Machine
Certification: CE, ISO
Model Number: IN-DT3030
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Mobile Phone Repeated Fall Drop Test Machine: Standard export wooden case with operation manual and video inside.
Delivery Time: Mobile Phone Repeated Fall Drop Test Machine: Shipped in 15 days after payment
Payment Terms: D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 200 sets per month
Contact Now
Detailed Product Description
Test Amount: 2 PCS Test Load: 1Kgf, 2Kgf(max)
Drop Height: 0 - 300mm (or Specified) Test Speed: 5 - 25 Cycles/min
Test Cycle: 1~999,999times (cycle) Dimension: W850xH370xD850mm
Weight: About 80kg Power Supply: AC220V 50Hz 3A Or Specified By User
Highlight:

Micro Drop Testing Machine

,

1Kgf Drop Testing Machine

,

300mm Free Fall Drop Test Machine

1Kgf 2Kgf 300mm Micro Drop Testing Machine For Mobile Phone, Smartphone Repeated Fall Drop Test Machine







Application:



Mobile Phone Repeated Drop Testing Machine is apply for micro-drop repeat testing of mobile phone, tablets, electronic dictionary, etc. To check if the products function normal or not after certain cycles tests.



Features:



(1) All the testing conditions is inputted by touch panel directly.

(2) Adopt Japan SMC precise pneumatic component, durable using.

(3) Adopt touch panel+PLC as program control.



Specification:



 Products  Micro Drop Testing Machine
 Model  DT3030
 Test amount  2 PCS
 Test load (max)  2Kgf (max)
 Drop height  0 - 300mm (or specified)
 Test speed  5 - 25 cycles/min
 Test cycle  1~999,999times (cycle)
 Dimension (WxDxH)  850x370x850mm
 Weight  About 80kg
 Air source  ≥0.5MPa
 Power supply  AC220V 50Hz 3A or specified by user



Test Introduction:



1. Faces drop test



1Kgf 2Kgf 300mm Micro Drop Testing Machine For Mobile Phone 0



2. Sides drop test



1Kgf 2Kgf 300mm Micro Drop Testing Machine For Mobile Phone 1



3. Corner test



1Kgf 2Kgf 300mm Micro Drop Testing Machine For Mobile Phone 2
