IF2A1-100KN Servo Controlled Universal Tensile Testing Machine 3 Phase Power Supply And Closed-loop Control Software

IF2A1-100KN Servo Controlled Universal Tensile Testing Machine 3 Phase Power Supply And Closed-loop Control Software

  • IF2A1-100KN Servo Controlled Universal Tensile Testing Machine 3 Phase Power Supply And Closed-loop Control Software
  • IF2A1-100KN Servo Controlled Universal Tensile Testing Machine 3 Phase Power Supply And Closed-loop Control Software
IF2A1-100KN Servo Controlled Universal Tensile Testing Machine 3 Phase Power Supply And Closed-loop Control Software
Product Details:
Place of Origin: Made In China
Brand Name: Infinity Machine
Certification: CE ISO
Model Number: IF2A1-100KN
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiate
Packaging Details: Clear sheet+sponge+wood carton
Delivery Time: 20-30 days after order confirmed
Payment Terms: TT PAYPAL Moneygram and so on
Supply Ability: 200 sets / month
Contact Now
Detailed Product Description
Unit (switchable): N, KN, Kgf, Lbf, Mpa, Lbf/In2, Kgf/mm2 Stroke (exclude The Grips): 650mm, 800mm (optional)
Transmission Rod: High Accuracy Ball Screw Main Unit Weight: 1500 Kg
Test Speed: 0.001~300mm/min Displacement Resolution: 0.001mm
Purpose: This Machine Is Suitable For Adhesive Tape, Rubber, Plastic, Sponge, Waterproof Materials, Electric Wire & Cable, Textile, Net Rope, Non-woven Fabrics Etc, Nonmetal Materials And Metallic Thread, Metal Foil, Steel Plate And Metal Rod To Do Tensile, Compres Feature3: Superior Software Program: Can Achieve The Closed Loop Control In Force Value, Speed & Displacement, So Can Satisfy The Fatigue Test Of Rubber And Durable Test Of Other Material In The Condition Of Low Cycle. Can Record And Memorize The Whole Testing Data.
Highlight:

IF2A1-100KN Universal Tensile Testing Machine

,

Servo Controlled tensile testing machine price

,

3 Phase universal tensile testing machine

IF2A1-100KN Servo Controlled Universal Tensile Testing Machine 3 PHASE Power Supply and Closed-loop Control Software

Product Description:

The Servo Controlled Universal Tensile Testing Machine is available in two effective widths, 400mm and 600mm (optional), allowing for a versatile range of testing applications. The main unit dimension (WxDxH) measures at 1220x720x2200mm, providing a large testing area for a variety of materials.



The Load resolution of the Servo Controlled Universal Tensile Testing Machine is an impressive 1/500,000, allowing for the detection of even the smallest changes in the material being tested. The main unit weight is 1500 Kg, ensuring a stable and reliable testing environment.

IF2A1-100KN Servo Controlled Universal Tensile Testing Machine 3 Phase Power Supply And Closed-loop Control Software 0

Our Servo Controlled Universal Tensile Testing Machine is perfect for testing the mechanical properties of materials such as metals, plastics, and rubber. It can be used for applications such as tension, compression, bending, shearing, and peeling tests.



With its advanced technology and precision engineering, our Servo Controlled Universal Tensile Testing Machine is the ideal solution for laboratories seeking the highest level of accuracy and reliability in their testing procedures.

IF2A1-100KN Servo Controlled Universal Tensile Testing Machine 3 Phase Power Supply And Closed-loop Control Software 1

Features:

  • Product Name: Servo Controlled Universal Tensile Testing Machine
  • Purpose: Suitable for testing nonmetal materials such as adhesive tape, rubber, plastic, sponge, waterproof materials, electric wire & cable, textile, net rope, non-woven fabrics etc, and metallic materials such as metal foil, steel plate, and metal rod for tensile, compression, bending, peeling, cutting, tearing, and shearing tests.
  • Computer Control Style: RS-8000A
  • Load resolution: 1/500,000
  • Load accuracy: ±0.25%
  • Unit (switchable): N, KN, Kgf, Lbf, Mpa, Lbf/In2, Kgf/mm2
  • Superior Software Program: Can achieve closed loop control in force value, speed & displacement, so can satisfy the fatigue test of rubber and durable test of other material in the condition of low cycle. Can record and memorize the whole testing data. Also had many kinds of analysis curve: stress vs strain curve, strength vs deformation curve, strength vs displacement curve, strength vs time curve, time vs deformation curve.
IF2A1-100KN Servo Controlled Universal Tensile Testing Machine 3 Phase Power Supply And Closed-loop Control Software 2

Technical Parameters:

Purpose This Machine Is Suitable For Adhesive Tape, Rubber, Plastic, Sponge, Waterproof Materials, Electric Wire & Cable, Textile, Net Rope, Non-woven Fabrics Etc, Nonmetal Materials And Metallic Thread, Metal Foil, Steel Plate And Metal Rod To Do Tensile, Compression, Bending, Peeling, Cutting, Tearing Shearing Tests. Computer Control Style RS-8000A ( It Is Used For Spot Test In Production Line, Can Do Many Data Analysis And Print The Test Report, Also Can Used For Material’s Cyclic Test And Holding Test ).
Transmission rod High Accuracy Ball Screw
Test speed 0.001~300mm/min
Unit (switchable) N, KN, Kgf, Lbf, Mpa, Lbf/In2, Kgf/mm2
Speed accuracy ±0.5%
Feature2 High Performance: Automatic Broken Identification, Automatically Return, Point Collected By Hand, Units Switching And 9 Kinds Of Languages Can Be Selected: Chinese, English, Japanese, Germany, French, Russian, Spanish And Portuguese.
Main unit dimension (WxDxH) 1220x720x2200mm
Software Closed-loop Control Software
Feature3 Superior Software Program: Can Achieve The Closed Loop Control In Force Value, Speed & Displacement, So Can Satisfy The Fatigue Test Of Rubber And Durable Test Of Other Material In The Condition Of Low Cycle. Can Record And Memorize The Whole Testing Data. And Also Had Many Kinds Of Analysis Curve: Stress Vs Strain Curve, Strength Vs Deformation Curve, Strength Vs Displacement Curve, Strength Vs Time Curve, Time Vs Deformation Curve.
Applications Use In Testing Adhesive Tape, Motorcar, Ceramics, Composite Materials, Architecture, Food, Medical Equipment, Metal Wire, Rubber, Plastic, Textile, Wood, Communication.
IF2A1-100KN Servo Controlled Universal Tensile Testing Machine 3 Phase Power Supply And Closed-loop Control Software 3

Applications:

The Infinity Machine IF2A1-100KN is a high-precision tensile testing machine designed and manufactured in China. It boasts of CE and ISO certification, ensuring that it meets international standards for quality and safety. With a minimum order quantity of 1 and negotiable pricing, this machine is an excellent investment for any company that requires a reliable and accurate testing machine for their products.



The IF2A1-100KN is equipped with an AC servo motor that drives a high-precision ball screw working with a high-precision explosion-proof load cell, ensuring that the strength accuracy reaches ±0.25% and displacement accuracy reaches 0.001mm. This feature makes it an ideal choice for companies that require high accuracy and repeatability in their testing processes.



The testing machine has a capacity of 100KN, making it suitable for testing a wide range of materials, including metals, plastics, rubber, and textiles. It is an excellent machine for testing the mechanical properties of materials, including tensile strength, compression strength, flexural strength, and shear strength.



The IF2A1-100KN is a versatile machine that can be used in various applications and scenarios. It is suitable for use in quality control labs, research and development labs, universities and colleges, and manufacturing facilities. It is ideal for testing raw materials, finished products, and components. It can also be used for testing products that require a high degree of precision and accuracy, such as medical devices, aerospace components, and automotive parts.



The machine has a test speed of 0.001~300mm/min, allowing for fast and efficient testing of materials. The transmission rod is a high-accuracy ball screw, ensuring that the machine is reliable and robust, providing long-lasting service to its users. It is a servo-controlled material testing equipment, which means that it is easy to operate and can be controlled using a computer or a touch screen.



The IF2A1-100KN is easy to package and transport, with packaging details consisting of clear sheet+sponge+wood carton. The delivery time is 20-30 days after order confirmation, and the payment terms include TT, PayPal, Moneygram, and other options. The supply ability is 200 sets per month, ensuring that the machine is readily available for purchase by interested parties.



In conclusion, the Infinity Machine IF2A1-100KN is a high-precision tensile testing machine that is suitable for a wide range of materials testing applications. Its high accuracy, reliability, and ease of use make it an excellent investment for companies and organizations that require a reliable and accurate testing machine for their products.

IF2A1-100KN Servo Controlled Universal Tensile Testing Machine 3 Phase Power Supply And Closed-loop Control Software 4

Customization:

Infinity Machine offers a high-precision Tensile Testing Machine, Model Number IF2A1-100KN, made in China. This Servo Controlled Material Testing Equipment has a certification of CE and ISO. The minimum order quantity is 1 and the price is negotiable. The packaging details include a clear sheet, sponge, and wood carton. The delivery time is 20-30 days after order confirmation. Payment terms accepted are TT, PAYPAL, Moneygram, and more. The supply ability is 200 sets per month.



The unit is switchable between N, KN, Kgf, Lbf, Mpa, Lbf/In2, and Kgf/mm2. The test speed ranges from 0.001~300mm/min. This Machine is suitable for testing Adhesive Tape, Rubber, Plastic, Sponge, Waterproof Materials, Electric Wire & Cable, Textile, Net Rope, Non-woven Fabrics Etc, Nonmetal Materials And Metallic Thread, Metal Foil, Steel Plate And Metal Rod to do Tensile, Compression, Bending, Peeling, Cutting, Tearing Shearing Tests. The computer control style RS-8000A is used for spot test in production line, can do many data analysis and print the test report, also can used for material’s cyclic test and holding test.

The main unit dimension (WxDxH) is 1220x720x2200mm and the weight is 1500 Kg.



Support and Services:

The Servo Controlled Universal Tensile Testing Machine product comes with a range of technical support and services to ensure optimal performance and reliability, including:

  • Installation and setup
  • Training and user manuals
  • Calibration and maintenance
  • Repairs and spare parts
  • Software updates and upgrades
  • Technical consultations

Our team of experienced technicians and engineers are dedicated to providing exceptional support and service to our customers, ensuring their satisfaction and success in using our Universal Testing Machine product.



Packing and Shipping:

Product Packaging:

The Servo Controlled Universal Tensile Testing Machine is securely packaged in a durable cardboard box with foam inserts to protect it during shipping.

Shipping:

We offer free shipping for the Universal Testing Machine within the continental United States. For international orders, shipping costs will be calculated at checkout.

All orders are processed within 1-2 business days and shipped via UPS or FedEx Ground. Once your order has shipped, you will receive a tracking number via email.



FAQ:

Q: What is the brand name of this testing machine?

A: The brand name of this testing machine is Infinity Machine.

Q: What is the model number of this testing machine?

A: The model number of this testing machine is IF2A1-100KN.

Q: Where is this testing machine made?

A: This testing machine is made in China.

Q: What certifications does this testing machine have?

A: This testing machine has CE and ISO certifications.

Q: What is the minimum order quantity for this testing machine?

A: The minimum order quantity for this testing machine is 1.

Q: What is the price of this testing machine?

A: The price of this testing machine is negotiable.

Q: What are the packaging details for this testing machine?

A: The packaging details for this testing machine are clear sheet+sponge+wood carton.

Q: What is the delivery time for this testing machine?

A: The delivery time for this testing machine is 20-30 days after order confirmed.

Q: What are the payment terms for this testing machine?

A: The payment terms for this testing machine are TT, PAYPAL, Moneygram, and so on.

Q: What is the supply ability for this testing machine?

A: The supply ability for this testing machine is 200 sets per month.
