≤±2C Temperature Deviation Walk-in Constant Temperature Humidity Testing Chamber

≤±2C Temperature Deviation Walk-in Constant Temperature Humidity Testing Chamber

  • ≤±2C Temperature Deviation Walk-in Constant Temperature Humidity Testing Chamber
  • ≤±2C Temperature Deviation Walk-in Constant Temperature Humidity Testing Chamber
≤±2C Temperature Deviation Walk-in Constant Temperature Humidity Testing Chamber
Product Details:
Place of Origin: MADE IN CHINA
Brand Name: Infinity
Certification: CE ISO
Model Number: IE8-15
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiate
Packaging Details: Clear sheet+sponge+wood carton
Delivery Time: 20-30 days after order confirmed
Payment Terms: TT PAYPAL Moneygram and so on
Supply Ability: 200 sets / month
Contact Now
Detailed Product Description
Observation Window: Install 1 Rectangular W400*H650mm Multi-layer Insulated Glass Observation Window With Electronic Anti-fog Control Panel: Controller Display Screen, Operation Buttons, Over-temperature Insulation Setting Device, USB Interface, Emergency Stop Switch, Running Indicator Light, Fault Indicator Light, Buzzer, Equipment Timer
Main Structure Design: It Consists Of Four Parts: Sheet Metal Area, Circuit Area, Freezing Area, And Waterway Area. Activity Slope: Equipped With 2 Movable Slopes To Facilitate Products Entering And Exiting The Test Box
Predetermined Area: Temperature: Adjust According To The Temperature Working Range Of The Equipment (upper Limit +5℃, Lower Limit -5℃) Humidity: (0~100)%RH (temperature And Humidity Test Equipment) Quality Assurance: From The Date Of Acceptance, The Company Will Repair The Equipment Completely Free Of Charge During The One-year Quality Guarantee Period (except For Damage Caused By Natural Disasters, Power Abnormalities, Improper Use And Improper Maintenance), Provided
Outer Box Size: W3900×D2700×H2800mm Failure Protection: Cut Off The Control Power When An Abnormal Fault Occurs And Fault Cause Indication And Alarm Output Signals. Emergency Stop Alarm Button (Stop The Equipment Directly In Unexpected Situations), Equipped With Sound And Light Alarm Prompts
Highlight:

Walk-in Humidity Testing Chamber

,

Constant Temperature Humidity Testing Chamber

≤±2℃ Temperature Deviation Walk-in Constant Temperature Humidity Testing Chamber

Product Description:

One of the key features of the Constant Temperature Humidity Climatic Test Chamber is its protocol. This chamber can communicate with the battery charge and discharge tester and can be integrated into the charge and discharge tester software. The temperature and humidity adjustment of the environmental box can be controlled through the software, making it easy to operate and monitor.



The packaging of the Constant Temperature Humidity Climatic Test Chamber is also noteworthy. It comes with a transport packaging box that meets the requirements of QB/BWD008-2001, ensuring that it is safe and secure during transportation.



Another important feature of the Constant Temperature Humidity Climatic Test Chamber is its test hole. There are 2 φ100mm holes on the side of the body, 2 stainless steel hole covers, and 2 φ100mm silicone plugs. This allows for easy access and connectivity when conducting tests.



The structure of the Constant Temperature Humidity Climatic Test Chamber is a single door split assembly type. This design makes it easy to install and maintain, while also providing excellent insulation and stability.



When it comes to protective features, the Constant Temperature Humidity Climatic Test Chamber has several. Its humidification system has water shortage protection, humidification pipe overheating protection, and humidification barrel dry burning protection. It also comes with a switch set for humidification water storage water level too low protection and a heating system protection switch set for heater short circuit protection. Additionally, this chamber has a temperature and humidity over-temperature balance device.



Overall, the Constant Temperature Humidity Climatic Test Chamber is a reliable and efficient tool for conducting large-scale environmental testing. Its advanced features and protective measures make it an ideal choice for industrial, research, and testing facilities.



Features:

  • Product Name: Walk-in Constant Temperature Humidity Testing Chamber
  • Curve recording function: It Has Battery-protected RAM That Can Save The Device’s Setting Values, Sampling Values And Sampling Time; The Maximum Recording Time Is 350 Days (when The Sampling Period Is 1.5min) The Controller's Memory Can Automatically Record Test Curves And Data, Equipment Status, Alarm Status, Etc., And Can Be Downloaded Via USB
  • Monitor: 10.2-inch TFT Color LCD Display
  • Venue requirements:
    • The Ground Is Flat, Well Ventilated, And Does Not Contain Flammable, Explosive, Corrosive Gases And Dust
    • There Are No Strong Electromagnetic Radiation Sources Nearby
    • A Drainage Floor Drain Is Provided Near The Equipment.
    • Site Ground Load-bearing Capacity: Not Less Than 800KG/㎡
    • Leave Adequate Maintenance Space Around The Equipment
  • Other:
    • Comply With GB 50050-2007 Industrial Circulating Cooling Water Treatment Design Specifications
    • It Is Recommended To Install "Clear Water Hibiscus" Electro-adsorption Circulating Water Treatment Equipment On The Waterway (scale Removal, Scale Absorption, Sterilization And Algae Removal) (If Circulating Chilled Water From The Air-conditioning System Is Used, The User Must Declare It In Advance)
  • Base plate material: Made Of SUS # 304/3.0mm Thick Anti-slip Stainless Steel Plate And Integrally Welded To Avoid Water Leakage

Keywords: Walk-in Temperature and Humidity Control Chamber, Walk-in Temperature and Humidity Test Chamber, Constant Temperature Humidity Climatic Test Chamber



Technical Parameters:

Product Name

Walk-in Constant Temperature Humidity Testing Chamber

Temperature Fluctuation ≤±0.5℃(no Load)
Cooling Method Water-cooled
Failure Protection Cut Off The Control Power When An Abnormal Fault Occurs And Fault Cause Indication And Alarm Output Signals. Emergency Stop Alarm Button (Stop The Equipment Directly In Unexpected Situations), Equipped With Sound And Light Alarm Prompts
Specimen Limits This Test Equipment Prohibits: Testing And Storage Of Explosive, Flammable And Volatile Substance Samples Testing And Storage Of Corrosive Substance Samples Testing Or Storage Of Biological Specimens Testing And Storage Of Samples From Strong Electromagnetic Emission Sources Testing And Storage Of Radioactive Material Samples Testing And Storage Of Highly Toxic Substance Samples Testing And Storage Of Samples That May Produce Highly Toxic Substances During Testing Or Storage
Main Structure Design It Consists Of Four Parts: Sheet Metal Area, Circuit Area, Freezing Area, And Waterway Area.
Communication Connection The Cabinet Is Equipped With A Touch Screen Display With A Chinese Operation Interface. There Are Pictures And Solutions For Checking Alarm Information. The Operation Is Convenient And Intuitive. The Equipment Can Be Connected To The Computer Host Through The Network Port, And Real-time Data Of The Equipment Temperature Can Be Collected At The Same Time;
Overload Protection Device AC Power Supply, Three-phase Power Supply Under And Reverse Phase Protection And Each Load Over Current (overload) Free-standing Studio Over-temperature Protection Fan Overheat Protection
Other Configurations 5 Meters Of Cable 4 Points Of Drainage Hose, 10 Meters Each 4-point Water Inlet And Pressure-resistant Movable Hose, 5 Meters Long
Outer Box Material The Outer Box Is Made Of Spray-coated Galvanized Color Steel Plate + Insulation Material + 304 Stainless Steel Plate Composite Assembly Plate, With A Total Thickness Of ≥150mm
Inner Box Size W2400×D2400×H2500mm


Applications:

The Infinity IE8-15 Constant Temperature and Humidity Machine, made in China, is a highly reliable product that is perfect for a variety of occasions and scenarios. With CE and ISO certification and a minimum order quantity of 1, its price is negotiable and it is packaged with clear sheet+sponge+wood carton. With a delivery time of 20-30 days after order confirmed and supply ability of 200 sets/month, this product is sure to meet your needs.



The temperature fluctuation of this Walk-in Temperature and Humidity Test Chamber is ≤±0.5℃(no Load), and the water pressure for the circulating cooling water supply is 0.2MPa~0.5MPa. The design and construction of the cooling water pipeline system should ensure that the pressure at the refrigerator inlet is 0.2MPa ~ 0.5MPa under the rated flow rate, and the pressure drop from the refrigerator outlet to the cooling water tower is not greater than 0.05MPa. With a 10.2-inch TFT color LCD display, this Walk-in Temperature and Humidity Test Chamber has a display resolution of Temperature: 0.01℃, Time: 0.1min, and Humidity: 0.1%RH (temperature and humidity test equipment).



This Constant Temperature and Humidity Machine is packed with features that make it easy to operate, energy-saving, and highly reliable. Its gas-liquid bypass mode is designed for energy-saving and consumption reduction, while its programmable color LCD touch controller can be combined with PID control and has flexible experimental data recording and processing methods. All key components are imported to ensure service life and reliability.



Whether you need to test electronic products, plastics, chemicals, food, or other materials, the Infinity IE8-15 Constant Temperature and Humidity Machine is the perfect choice. Its high reliability and energy-saving features make it an ideal choice for any laboratory or testing facility. Don't hesitate to contact us today to learn more about this amazing product.



Customization:

Brand Name: Infinity

Model Number: IE8-15

Place of Origin: MADE IN CHINA

Certification: CE ISO

Minimum Order Quantity: 1

Price: Negotiate

Packaging Details: Clear sheet+sponge+wood carton

Delivery Time: 20-30 days after order confirmed

Payment Terms: TT PAYPAL Moneygram and so on

Supply Ability: 200 sets / month

Predetermined area: Temperature: Adjust According To The Temperature Working Range Of The Equipment (upper Limit +5℃, Lower Limit -5℃) Humidity: (0~100)%RH (temperature And Humidity Test Equipment)

Structure: Single Door Split Assembly Type

Box door structure:

  • Flat Recessed Rotatable Handle
  • Hinge: It Can Prevent The Door From Shaking At Will, And Its Material Is SUS #304
  • 2 Pieces Of High-tensile Silicone Foam Fasteners That Are Resistant To High And Low Temperatures
  • The Inner Frame Is Embedded With Heating Wire To Prevent Frost
  • The Door Has A Protective Device That Can Be Opened From The Inside To Prevent People From Being Locked Out

Overload protection device:

  • AC Power Supply, Three-phase Power Supply Under And Reverse Phase Protection And Each Load Over Current (overload)
  • Free-standing Studio Over-temperature Protection Fan Overheat Protection

Body Color: White (or Customized)

Keywords: Constant Temperature Humidity Climatic Test Chamber, Constant Temperature and Humidity Machine, Walk-in Temperature and Humidity Test Chamber



Support and Services:

The Constant Temperature and Humidity Test Chamber is designed to provide precise and stable temperature and humidity control for various testing applications. Our technical support and services for this product include:

- Installation and setup assistance

- Training on operation and maintenance

- Troubleshooting and repair services

- Calibration and certification services

- Replacement parts and accessories

Our team of experienced technicians is dedicated to ensuring that your Constant Temperature and Humidity Test Chamber operates optimally and reliably. Contact us for any technical support or service needs.



Packing and Shipping:

Product Packaging:

The Constant Temperature And Humidity Test Chamber will be packed securely in a wooden crate to ensure maximum protection during shipping. All necessary accessories and instruction manuals will be included in the package.

Shipping:

The Constant Temperature And Humidity Test Chamber will be shipped via a reputable courier service, such as DHL or FedEx. The shipping cost will be calculated based on the destination and weight of the package. A tracking number will be provided to the customer once the package has been shipped.



FAQ:

Q: What is the brand name of this product?

A: The brand name of this product is Infinity.

Q: What is the model number of this product?

A: The model number of this product is IE8-15.

Q: Where is this product made?

A: This product is made in China.

Q: What certifications does this product have?

A: This product has CE and ISO certifications.

Q: What is the minimum order quantity for this product?

A: The minimum order quantity for this product is 1.

Q: What is the price of this product?

A: The price of this product is negotiable.

Q: What are the packaging details for this product?

A: The packaging details for this product include clear sheet, sponge, and wood carton.

Q: What is the delivery time for this product?

A: The delivery time for this product is 20-30 days after order confirmed.

Q: What payment terms are accepted for this product?

A: The payment terms accepted for this product include TT, PayPal, Moneygram, and other commonly used methods.

Q: What is the supply ability for this product?

A: The supply ability for this product is 200 sets per month.
