| Place of Origin: | Made in China |
| Brand Name: | Infinity Machine |
| Certification: | ISO |
| Model Number: | IN-S9001G |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Switches Compression Force Tester: Standard export wooden case with operation manual and video inside. |
| Delivery Time: | Computer Button Compression Force Tester: Shipped in 15 days after payment |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 sets per month |
| Position Resolution: | 0.001mm | Position Accuracy: | ±0.03mm |
|---|---|---|---|
| Unit: | Gf,kgf,N, Lb Mm,cm,In | Load Accuracy: | ±0.5% |
| Dimension: | W860*D755*H1780mm/W1150*D755*H1850mm | Power: | AC220V 50Hz 6A Or AC110V 60Hz 10A |
| Weight: | 425kg/550kg | Warranty: | 1 Year |
| High Light: | Keyboard Compression Force Tester,100kgf Compression Force Tester,50kgf Compression Test Machine |
||
Model:S9001G
Specialties:
1. Button compression force tester have X, Y, Z axes, X,Y are to move the testing platform, so that it can realize the multi-points compression test for the buttons force test and the electronic products compression test; Z axis is connected to the transducer to apply the test force, collect the test force and control the compression time.
2. Key load force tester is controlled by professional software. It can set test force, test time, test cycles and test speed. Besides, keystroke test machine can collect test force, test time, test speed to generate the test graph.
3. X,Y,Z axes are driven by servo motor from Japanese Panasonic to drive; transmission by precise ballscrew which can achieve the low noise and long durability.
4. Keypress compression loading tester has a controlled box, you can use control the machine by control box.
5. This multifunctional keypress compressing test machine is floor type, compact structure, small footprint.
6. There have Chinese and English language interface for option and switch the unit (N,Lb,gf,kgf) freely .
7. Testing method can be set, saved or called for use from the saving record, and you can print data or curve.
8. The life damping curve can be created, the test report can be converted to Excel and PDF file format.
Specification:
| Products | Button compressing force test machine |
| Model | S9001G |
| Driving method of Z axis | Servo motor of Japanese Panasonic |
| Test range of load | 0~1000N(100kgf) |
| Range of driving (up and down) | 0~200mm |
| Resolution of load | 0.01N |
| Accuracy of load | ±0.5%F.S |
| Test range of displacement | 0~150mm |
| Resolution of displacement | 0.001mm |
| Accuracy of displacement | ±0.03mm |
| Range of test speed | 0.1~200mm/min |
| Driving method of X-Y axis | Servo motor from Panasonic |
| Control way | X:(right and left) Y:(forward and backward) |
| Driving range | X:0~460mm Y:0~300mm |
| Resolution of displacement | 0.002mm |
| Accuracy of displacement | ±0.05mm |
| Range of moving speed | 5~200mm/sec |
| Max size of specimen | W500xD260mmxH150mm |
| Weight | About 350kg |
| Size of machine | W1270xD750xH1890mm |
Application:
Servo control keypress compression force tester is controlled by X,Y,Z axis. Keystroke force distance test machine is suitable for all kinds of buttons, switches, metal shrapnel, computer buttons, mobile phone buttons, car buttons, remote controls, rubber etc. for doing load-stroke curve test, down force, rebound force test and so on. For choosing suitable fixtures, force stroke testing machine can do button force, compression testing, 3 points bending test, 4 points bending test and so on.
Keystroke compression force test machine is control by computer, it is easy to operate, storing test materials automatically: load-stroke curve, life decline curve, test result, moreover the test method can be preserved and adjusted.
Testing Report:
Service:
For more information about keyboard compression force testing machines, please contact us.
