Digital Automatic Compressive Strength Testing Machine FOR Cardboard Paper

Digital Automatic Compressive Strength Testing Machine FOR Cardboard Paper

    • Digital Automatic Compressive Strength Testing Machine FOR Cardboard Paper
    • Digital Automatic Compressive Strength Testing Machine FOR Cardboard Paper
    • Digital Automatic Compressive Strength Testing Machine FOR Cardboard Paper
  • Digital Automatic Compressive Strength Testing Machine FOR Cardboard Paper

    Product Details:

    Place of Origin: Made in China
    Brand Name: Infinity Machine
    Certification: CE, ISO
    Model Number: RS-8403A

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiable
    Packaging Details: Standard export wooden case with operation manual and video inside.
    Delivery Time: Shipped in 15 days after payment
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 200 sets per month
    Contact Now
    Detailed Product Description
    Capacity(optional): 0~100kg/cm2 Induction Mode: Pressure Transformer
    Stroke Resolution: 0.001mm Hydraulic Fluid: 85% Synthetic Ester, 15%distilled Water
    Weight: 65 Kg Dimension (WxDxH): 500×380×690mm
    Power Supply: AC220V 3A Or Specified By User Warranty: 1 Year



    Digital Type Automatic Cardboard Paper Bursting Strength Tester White Color



    Model: RS-8403A



    Purpose:



    Apply for industrial of electronic parts, houseware, wire, metal, bicycle, handbag, foodstuff, footwear, furniture, etc. to do burst resistance strength test on sample and corrugated cartons, also can be used for synthetic leather testing & textile testing & paper and paperboard testing.

    With quakeproof motor driver, operated by worm driving, and then forced on testing sample at speed of 170±15ml/min, the digital load cell will show the sample broken value.



    Test standard:



    ISO-2759, GB/T-6545, JIS-P8112, L1018, ASTM-2210, TAPPI-T403



    Feature:



    1.Just press “test” button, then the tester can clamp the sample and load the force automatically, after broken, will release the force and calculate the strength automatically, also can store and print the testing result;

    2. Computer can collect the test data, LCD digital display: measured value, Max. broken value, can identify the sample broken and release the force automatically, easy operation and high accuracy;

    3. After testing, can print the test result accordingly (printer can be optioned);

    4. Adopt precision quakeproof motor, high quality and durability;

    5. High resolution, 1/50000, top grade in this industrial;

    6. Unit can be switched: kgf/cm2, MPa, psi, Lbf/in2;



    Specification:



    Model RS-8403A
    Capacity (optional) 0~100kg/cm2
    Induction mode Pressure transformer
    Hydraulic fluid 85% synthetic ester, 15%distilled water
    Indication mode Electrical device
    Motor 1/4HP motor (shake-proof)
    Weight 65 kg
    Dimension (WxDxH) 500×380×690mm
    Power supply AC220V 3A or specified by user




    Digital Automatic Compressive Strength Testing Machine FOR Cardboard Paper



    Digital Automatic Compressive Strength Testing Machine FOR Cardboard Paper
