| Place of Origin: | MADE IN CHINA |
| Brand Name: | INFINITY |
| Certification: | CE ISO |
| Model Number: | IE10 |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Clear sheet+sponge+wood carton |
| Delivery Time: | 20-30 days after order confirmed |
| Payment Terms: | TT PAYPAL Moneygram and so on |
| Supply Ability: | 200 sets / month |
| Humidity Control Range: | 20%R.H～98%R.H | Models: | IE10 150L ,IE10 225L, IE10 408L, IE10 800L ,IE10 1000L |
|---|---|---|---|
| Application: | Suitable For Electrical, Electronic, Mechanical And Other Products, Parts, Materials And Other Products, High And Low Temperature, Wet And Hot Test, Simulate The Temperature And Humidity Change Conditions Of Products, Parts, Materials And Other Quality And | Inspection Window: | The W 300×H 400mm Observation Window Is Installed On The Door Of The Box, And Multi-layer Hollow Electro Thermal Coated Glass Can Effectively Keep Heat And Prevent Condensation. |
| Humidity Fluctuation: | ±1.0％RH | Humidity Deviation: | ±3.0％RH（＞75％RH） ±5.0％RH（≤75％RH） |
| Sample Holder: | Stainless Steel Sample Rack 2 Layers, Height Adjustable, Bearing Weight 30kg/ Layer. | Safety Protection Device: | Heater Anti-burning Protection; Humidifier Anti-burn Protection; Heater Overcurrent Protection; Humidifier Overcurrent Protection; Circulating Fan Overcurrent Overload Protection; Compressor High Pressure Protection; Compressor Overheat Protection; Compres |
The Programmable Constant Temperature And Humidity Test Chamber is a highly advanced industrial test chamber designed to provide precise and reliable testing conditions for various products and materials. With a temperature fluctuation of only ±0.5℃, this chamber is capable of maintaining a constant and accurate temperature throughout the testing process.
The chamber is equipped with a high-quality refrigeration compressor from France Tecumseh, a well-known and trusted brand in the industry. This fully closed compressor ensures efficient cooling and temperature control, making it ideal for conducting high and low temperature tests.
The Programmable Constant Temperature And Humidity Test Chamber is suitable for a wide range of products and materials, including electrical, electronic, and mechanical products. It is designed to simulate temperature and humidity change conditions, making it an essential tool for quality and reliability testing.
The chamber features a large inspection window (W 300×H 400mm) on the door, allowing for easy observation of the testing process. The multi-layer hollow electro thermal coated glass provides clear visibility while also effectively keeping heat inside the chamber and preventing condensation.
Overall, the Programmable Constant Temperature And Humidity Test Chamber is a versatile and reliable industrial test chamber that is essential for conducting quality and reliability tests on various products and materials. Its precise temperature and humidity control, sturdy construction, and user-friendly features make it a valuable addition to any testing facility.
The INFINITY IE10 constant temperature and humidity test chamber is a high-quality, reliable and programmable equipment designed for environmental simulation reliability test of industrial products. It is equipped with advanced temperature and humidity control system, providing accurate and stable control of environmental conditions. This test chamber meets the performance requirements of GB5170.2.3.5.6-95, making it an ideal choice for various environmental testing needs.
The INFINITY IE10 constant temperature and humidity test chamber is designed for a wide range of applications and can be used in various scenarios, including:
With its accurate and stable temperature and humidity control, this test chamber is suitable for simulating various environmental conditions, such as high and low temperatures, constant and alternating humidity levels, and more. It can help ensure the reliability and quality of products, making it an essential equipment for industries such as automotive, electronics, aerospace, pharmaceuticals, and more.
To order the INFINITY IE10 constant temperature and humidity test chamber, please provide the following information:
For more information and customization options, please contact us. We look forward to working with you and providing high-quality and reliable equipment for your environmental testing needs.
| Model | IE10 150L | IE10 225L | IE10 408L | IE10 800L | IE10 1000L | ||||
| Temp. range | -40℃ ～ +150℃ | ||||||||
| Temp. fluctuation | ±0.5℃ | ||||||||
| Temp. uniformity | ≦2.0℃ | ||||||||
| Heating rate | from -40℃ to +100℃ within 60min (No load, ambient temperature +25℃) | ||||||||
| Temp. decrease rate | from +20℃ to -40℃ within 60min (No load, ambient temperature +25℃) | ||||||||
| Humidity control range | 20%R.H～98%R.H | ||||||||
| Humidity deviation |
±3.0％RH(＞75％RH) ±5.0％RH(≤75％RH) |
||||||||
| Humidity uniformity | ±3.0％RH(no load) | ||||||||
| Humidity fluctuation | ±1.0％RH | ||||||||
|
|
|||||||||
|
Inside dimensions: WxHxD(mm) |
500x600x500 | 500x750x600 | 600×850×800 | 1000×1000×800 | 1000×1000×1000 | ||||
|
Outside box size: WxHxD(mm) |
720×1500×1270 | 720×1650×1370 | 820×1750 ×1580 | 1220×1940 ×1620 | 1220×1940 ×1820 | ||||
| Warm-keeping box |
● Outer chamber material: high quality carbon steel plate, surface for electrostatic color spray treatment. The left side of the box is φ50mm diameter hole ● Inner material :SUS304# stainless steel plate. ● Insulation material: hard polyurethane foam insulation layer + glass fiber. |
||||||||
| Door | For a single door, install a heating wire in the door frame to prevent condensation in the door frame at low temperature. | ||||||||
| Inspection window | The W 300×H 400mm observation window is installed on the door of the box, and multi-layer hollow electro thermal coated glass can effectively keep heat and prevent condensation. | ||||||||
| Lighting device | 1 LED lighting device, installed on the window. | ||||||||
| Sample holder | Stainless steel sample rack 2 layers, height adjustable, bearing weight 30kg/ layer. | ||||||||
| Refrigeration compressor | France Tecumseh fully closed compressor | ||||||||
| Coolants | Non-fluorine environmental refrigerant R404A, in line with environmental regulations, safe and non-toxic | ||||||||
| Condenser system | air-cooled | ||||||||
| Safety protection device | Heater anti-burning protection; Humidifier anti-burn protection; Heater overcurrent protection; Humidifier overcurrent protection; Circulating fan overcurrent overload protection; Compressor high pressure protection; Compressor overheat protection; Compressor overcurrent protection; Overvoltage underinverse-phase protection; Circuit breaker; Leakage protection; Humidifier low water level protection; Tank low water level warning. | ||||||||
| Power | AC220V;50Hz;4.5KW | AC380;V50Hz;6KW | AC380;V50Hz;7KW | AC380;V50Hz;9KW | AC380;V50Hz;11KW | ||||
Brand Name: INFINITY
Model Number: IE10
Place of Origin: MADE IN CHINA
Certification: CE, ISO
Minimum Order Quantity: 1
Price: Negotiate
Packaging Details: Clear sheet+sponge+wood carton
Delivery Time: 20-30 days after order confirmed
Payment Terms: TT, PAYPAL, Moneygram, and more
Supply Ability: 200 sets / month
The INFINITY IE10 Constant Temperature and Humidity Test Chamber is designed for environmental simulation reliability testing of industrial products. It features high accuracy and wide control range for temperature and humidity control, and meets the performance requirements of GB5170.2.3.5.6-95 for Environmental Test Equipment for Electrical and Electronic Products.
±1.0％RH
Stainless Steel Sample Rack 2 Layers, Height Adjustable, Bearing Weight 30kg/ Layer
For more information about our Programmable Constant Temperature and Humidity Test Chamber and pricing, please contact us.
Environmental Test Chambers, Programmable constant temperature and humidity test chamber, Programmable constant temperature and humidity test chamber price
