800L Salt Mist Spray Test Chamber For Testing The Valid Content Product

Product Description:

Applications:

The INFINITY IE 41 Series Salt Spray Test Chamber is a state-of-the-art testing equipment designed to simulate and increase the impact of the environment on metal materials exposed to salt pollution. It is widely used in various industries for corrosion resistance testing, including automotive, aerospace, marine, and electronics.

• model	I E4160L	I E4190L	I E41120L	I E41160L	I E41200L
  Temperature range	5℃ ～ +85℃
  Temperature departure	±1℃
  Temperature fluctuation	±0.5℃
  Temperature uniformity	≦2.0℃
  Humidity range	20~100%R.H
  Humidity deviation	±2%R.H
  Relative humidity fluctuation	±2%R.H
  Humidity uniformity	±3%R.H
  Rising and cooling rate	RT →+85℃≤40 min RT→+0℃≤30 min Salt spray (35℃) dry (60℃.20~30%RH)≤30 min. Dry (60℃, 20-30% RH) and wet (50℃, 95% + / -5% RH) for 15 min. Moistet (50℃, 95% + / -5% RH) salt spray (35℃) for 30 min (immediate spray required after switching).
  Effective inner capacity	150L	270L	576L	800L	1200L
  Internal box size: WxHxD(mm )	600*500*500	900*600*600	1200*1000*600	1600*1000*600	2000*1000*600
  Out box size: WxHxD(mm )	1780*950*1300	2080*1050*1350	2380*1450*1450	2780*1450*1450	3180*1450*1450
  Box structure	● Test chamber box: using PP polypropylene board, the thickness of 10mm, temperature resistance of about 100 degrees. ● Laboratory outer box: using PP polypropylene board, thickness of 10mm, temperature resistance of about 100 degrees. ● Laboratory sealing cover: using PP polypropylene plate, thickness of 10mm, one-button automatic open cover, with transparent observation window, combined with the defogging device, Convenient clear observation of the test, temperature resistance of about 100 degrees.
  Water filling method	Automatic / manual dual water supply mode, automatic water inlet with a set of water purifier
  specimen holder	● The inner wall of PVC polyethylene dilute triangular tank box is used to place the dividing frame, the Angle of the test product can be adjusted at will, and the number of test pieces on all sides is completely consistent. ● At the bottom of the test box, the PP plate punching sample placement platform. The uniform opening on the platform surface will discharge the spray liquid quickly, and the large sample can be placed on the platform for testing.
  refrigeration compressor	France taikang fully closed compressor
  cooling medium	Non-fluorinated refrigerant R404A complies with environmental regulations, safe and non-toxic
  Condenser mode	air-cooled
  Safety protection device	refrigeration system	Compressor overheating protection Compressor overcurrent protection Over pressure and low pressure protection Condensate fan overheating protection
  	test box	Adjustable overtemperature protection Extreme overtemperature protection of the air conditioning channel Fan, motor superheater relay protection
  	heating system	Heating pipe dry burning protection alarm Abnormal water supply alarm Abnormal drainage alarm
  	other	earth leakage protection Overload and short-circuit protection The power supply lacks the reverse phase protection function
  weight (Kg)	About 300	About 400	About 500	About 600	About 700
  Power	AC380V;50Hz;7KW	AC380;V50Hz;9KW	AC380;V50Hz;11KW	AC 380;V50Hz;13KW	AC 380;V50Hz;15KW


• Box Structure:
  • Test Chamber Box: Using PP Polypropylene Board, The Thickness Of 10mm, Temperature Resistance Of About 100 Degrees.
  • Laboratory Outer Box: Using PP Polypropylene Board, Thickness Of 10mm, Temperature Resistance Of About 100 Degrees.
  • Laboratory Sealing Cover: Using PP Polypropylene Plate, Thickness Of 10mm, One-button Automatic Open Cover, With Transparent Observation Window, Combined With The Defogging Device, Convenient Clear Observation Of The Test, Temperature Resistance Of About 100 Degrees.
• Condenser Mode: Air-cooled
• Equipment Design Principle: The Equipment Is Designed To Simulate And Increase The Impact Of The Environment On Metal Materials Exposed To Salt Pollution And Can Accelerate Corrosion. The Equipment Includes The Test Method For Exposing The Sample Cycle To Salt Spray, Dry, Wet And Humid Environment. This Equipment Test Is A Comparative Test, And The Test Results Cannot Predict The Long-term Results Of The Corrosion Resistance Of The Same Metal Material Used In This Environmental Condition. However, This Method Still Provides Valuable Information On The Properties Of Materials Exposed To Salt-contaminated Environments Similar To The Test Conditions. Compared With Traditional Accelerated Corrosion Test, Such As Neutral Salt Spray Test (NSS), Acetate Salt Spray Test (AASS), Copper Accelerated Acetate Salt Spray Test (CASS).
• Humidity Uniformity: ±3%R.H

The INFINITY IE 41 Series Salt Spray Test Chamber is suitable for a variety of applications, including:

• Corrosion resistance testing of metal materials
• Quality control testing for automotive parts
• Evaluation of corrosion resistance for marine equipment
• Testing of electronic components for reliability in harsh environments
• Research and development of anti-corrosion coatings and materials

• High-quality construction with PP Polypropylene Board for durability and temperature resistance
• One-button automatic open cover with transparent observation window for convenient and clear observation of the test
• Air-cooled condenser for efficient and reliable performance
• Accurate and consistent humidity control with ±3%R.H uniformity
• Simulates and accelerates corrosion in a salt-contaminated environment for reliable and efficient testing
• Comparative testing method provides valuable information on the properties of materials in similar environmental conditions

With its advanced design and reliable performance, the INFINITY IE 41 Series Salt Spray Test Chamber is an essential tool for industries that require accurate and efficient corrosion resistance testing. Contact us today to learn more and discuss your testing needs.

Customization:

Brand Name: INFINITY

Model Number: IE 41 Series

Place of Origin: MADE IN CHINA

Certification: CE, ISO

Minimum Order Quantity: 1

Price: Negotiate

Packaging Details: Clear sheet+sponge+wood carton

Delivery Time: 20-30 days after order confirmed

Payment Terms: TT, PAYPAL, Moneygram and so on

Supply Ability: 200 sets / month

Weight (Kg): About 300, About 400, About 500, About 600, About 700

Humidity Uniformity: ±3%R.H

Humidity Range: 20~100%R.H

Relative Humidity Fluctuation: ±2%R.H

Rising and Cooling Rate: RT →+85℃≤40 Min, RT→+0℃≤30 Min, Salt Spray (35℃) Dry (60℃.20~30%RH)≤30 Min, Dry (60℃, 20-30% RH) And Wet (50℃, 95% + / -5% RH) For 15 Min, Moistet (50℃, 95% + / -5% RH) Salt Spray (35℃) For 30 Min (Immediate Spray Required After Switching).

Packing and Shipping:

Our salt spray test chamber (new) will be carefully packaged to better protect it during transportation.

The first layer of packaging will consist of a sturdy wooden crate to provide a strong and durable outer shell. Inside the crate, the chamber will be secured and protected with foam padding to prevent any damage from potential impacts during shipping.

Next, the crate will be securely strapped and sealed to ensure the chamber stays in place during transit. Fragile stickers will also be placed on the crate to alert handlers of the delicate contents inside.

For shipping, we offer both air and sea freight options. Our experienced logistics team will work with you to determine the best and most cost-effective method of transportation for your specific location.

Once the chamber arrives at its destination, it will be carefully unloaded and inspected to ensure it has arrived in perfect condition. Any necessary assembly and installation can also be arranged by our team upon request.

At Salt Spray Test Co., we take pride in our attention to detail and commitment to delivering our products safely and securely to our customers.
