| Place of Origin: | Made in China |
| Brand Name: | Infinity Machine |
| Certification: | CE, ISO |
| Model Number: | IN-DT3030 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Mobile Phone Repeated Drop Test Machine: Standard export wooden case with operation manual and video inside. |
| Delivery Time: | Mobile Phone Repeated Drop Test Machine: Shipped in 15 days after payment |
| Payment Terms: | D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 sets per month |
| Test Amount: | 2 PCS | Test Load: | 1Kgf, 2Kgf（max） |
|---|---|---|---|
| Drop Height: | 0 - 300mm (or Specified) | Test Speed: | 5 - 25 Cycles/min |
| Test Cycle: | 1~999,999times (cycle) | Dimension: | W850xH370xD850mm |
| Weight: | About 80kg | Power Supply: | AC220V 50Hz 3A Or Specified By User |
| High Light: | Touch Panel Micro Drop Tester,300mm Drop Tester,Mobile Phone Micro Drop Testing Machine |
||
Features:
(1) All the testing conditions is inputted by touch panel directly.
(2) Adopt Japan SMC precise pneumatic component, durable using.
(3) Adopt touch panel+PLC as program control.
Specification:
| Products | Repeat Micro Drop Test Machine |
| Model | IN-DT3030 |
| Test amount | 2 PCS |
| Test load (max) | 2Kgf (max) |
| Drop height | 0 - 300mm (or specified) |
| Test speed | 5 - 25 cycles/min |
| Test cycle | 1~999,999times (cycle) |
| Dimension (WxDxH) | 850x370x850mm |
| Weight | About 80kg |
| Air source | ≥0.5MPa |
| Power supply | AC220V 50Hz 3A or specified by user |
Test Introduction:
1. Faces drop test
2. Sides drop test
3. Corner test
Application:
Mobile Phone Repeated Drop Testing Machine is apply for micro-drop repeat testing of mobile phone, tablets, electronic dictionary, etc. To check if the products function normal or not after certain cycles tests.
FAQ:
| 1. How to choose the most suitable repeated drop test eqiupment from INFINITY MACHINE INC.? |
Our professional team will provide specialized suggestion to you when we received your testing requirements.
|
| 2. What’s the delivery term? |
At most of time, we have stock in the factory. If there is no stock, normally, the lead time is about 15-20 working days.
|
| 3. Do you accept customization service? |
Yes, of course, we are not only offer standard machines, but also provide customized service according to your request. If you have any testing requirements, please contact us.
|
| 4. Can we visit your factory before order? |
Sure, we sincerely welcome you to visit our factory, if it is not convenient for you to visit our facotry, you could arrrange your friends to visit our company as well.
|
| 5. Do you have customers in our country? |
Our equipment is not only sold in China (mainland, Hong Kong, Taiwan), but also sold to more than 70 countries, such as, The United States, Canada, Mexico, Germany, Britain, France, Italy, Sweden, Denmark, Poland, Portugal, the Netherlands, Ireland, Turkey, Hungary, Austria, Spain, Bosnia and Herzegovina, Romania, Bulgaria, Serbia, Belgium, Slovakia, Lithuania, Latvia, belarus, Russia, New Zealand, Australia, Vietnam, South Korea, Japan, Singapore, Malaysia, Thailand, the Philippines, the United Arab Emirates, Iran, Sudan, Kuwait, Saudi Arabia, Qatar, Uzbekistan, Lebanon, Sri Lanka, South Africa, Afghanistan, Botswana, Nigeria, Gambia, Namibia, Cameroon, Israel, Pakistan, Indonesia, India, Egypt, Brazil, Chile, Argentina, Colombia, Puerto Rico, Peru, Guatemala, Costa Rica, Uruguay and so on.
|
| 6. How about your warranty? |
Generally, we will provide 12 months warranty for testing machines.
|
| 7. How about the packing for testing machine, are there have safe protected during transportation? |
Usaully our equipment is packed by standard export wooden box, also, our products have been delivered to more than 70 countries, so we have rich experience to protect your machines.
|
| 8. What is the order process? |
Inquiry - quotation - communication - order confirming - deposit payment - production - testing and debugging - balance payment - packing - delivery - customer receiving - after service.
|
| 9. How to install and use the testing equipments? |
We will provide installation instructions to you, also, we will prepare user manual and operating video in English version for you. If you have any question about the machine, please contact us freely. |
