Concrete Compressive Strength Testing Machine Servo Control 300 KN Capacity

Concrete Compressive Strength Testing Machine Servo Control 300 KN Capacity

  • Concrete Compressive Strength Testing Machine Servo Control 300 KN Capacity
  • Concrete Compressive Strength Testing Machine Servo Control 300 KN Capacity
Concrete Compressive Strength Testing Machine Servo Control 300 KN Capacity
Product Details:
Place of Origin: Made in China
Brand Name: Infinity Machine
Certification: CE, ISO
Model Number: RS-8000A
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Standard export wooden case with operation manual and video inside.
Delivery Time: Shipped in 15 days after payment
Payment Terms: D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 200 sets per month
Contact Now
Detailed Product Description
Max. Capacity: 300KN Max. Stroke: 800mm
Effective Width: 400mm / 600mm Load Resolution: 1/500,000
Load Accuracy: ±0.25% Weight: 1500 Kg
Dimension: 1220x720x2200mm Power Supply: AC220V 15A Or Specified By User
High Light:

universal test machine

,

digital compression testing machine



Concrete Compressive Strength Testing Machine Servo Control 300 KN Capacity



Model: RS-8000A



Purpose:



This compressive strength testing machine is suitable for adhesive tape, rubber, plastic, sponge, waterproof materials, electric wire & cable, textile, net rope, non-woven fabrics etc, nonmetal materials and metallic thread, metal foil, steel plate and metal rod to do tensile, compression, bending, peeling, cutting, tearing shearing tests.

It is used for spot test in production line, can do many data analysis and print the test report, also can used for material’s cyclic test and holding test.



Features:



High accuracy:

Adopt AC servo motor to driving the high precise ball screw working, with high precise explosion-proof load cell. Strength accuracy reached to ±0.25% & displacement accuracy reach to 0.001mm.



Concrete Compressive Strength Testing Machine Servo Control 300 KN Capacity 0



Superior software program:

Can achieve the closed loop control in force value, speed & displacement, so can satisfy the fatigue test of rubber and durable test of other material in the condition of low cycle. Can record and memorize the whole testing data. And also had many kinds of analysis curve: stress vs strain curve, strength vs deformation curve, strength vs displacement curve, strength vs time curve, time vs deformation curve.



Multi-function:

Can coordinate with different grips, the tests of tensile, compression, bending, shearing, tearing, peeling, etc can be done.



Specification:



 Model  RS-8000A
 Capacity (optional)  100KN, 200KN, 300KN
 Unit (switchable)  N, KN, Kgf, Lbf, Mpa, Lbf/In2, Kgf/mm2
 Load resolution  1/500,000
 Load accuracy  ±0.25%
 Load range  Rangless
 Stroke (exclude the grips)  650mm, 800mm (optional)
 Effective width  400mm , 600mm (optional)
 Test speed  0.001~300mm/min
 Speed accuracy  ±0.5%
 Displacement resolution  0.001mm
 Software  Closed-loop control software
 Motor  AC servo Motor
 Transmission rod  High accuracy ball screw
 Main unit dimension (WxDxH)  1220x720x2200mm
 Main unit weight  1500 Kg
 Power Supply  AC220V 15A or specified by user



Picture:



Concrete Compressive Strength Testing Machine Servo Control 300 KN Capacity 1



Concrete Compressive Strength Testing Machine Servo Control 300 KN Capacity 2
